IRIS
Iris CMAC-NVR 16-Channel IP Network Recorder, 1TB, Recorder Only
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The CMAC-NVR is the network (IP) member of the CMAC range, recording and managing Iris IP cameras and any ONVIF Profile-S compliant third-party camera over a single camera network connection. It suits a fully digital, all-IP camera installation.
This X model is the standalone network video recorder. It outputs high-definition HDMI video to chart plotters, monitors and televisions and can be viewed and controlled through a web browser or app, with built-in WiFi and remote P2P connectivity for access on board or away from the boat. Where a plotter has no HDMI input, the Iris HDMI2IP encoder module re-encodes the output as an IP stream. For full chart-plotter integration and the on-screen virtual joystick, choose the IrisControl-hosting G model instead.
The integrated recorder is fully configurable for resolution, frame rate and motion-triggered recording, and ships with a 1TB drive in a removable anti-shock caddy that is expandable as storage needs grow.
PRODUCT DETAILS
- 16-channel network video recorder for IP cameras at 1080p
- Compatible with all Iris IP cameras and ONVIF Profile-S third-party cameras
- Standalone network video recorder (no IrisControl chart-plotter app)
- High-definition HDMI video output, with optional HDMI2IP encoding for non-HDMI plotters
- View and control via web browser or app
- Supplied with 1TB anti-vibration HDD caddy, expandable storage
- WiFi and remote P2P access to view your cameras on phone, tablet or computer
- Wide 12 to 24VDC input range and rugged, compact case
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Recorder
| Type | Network video recorder (IP cameras only) |
| Channels | 16 channels |
| Camera Capacity | 16 x IP cameras at 1920 x 1080 |
| Camera Support | All Iris IP cameras and ONVIF Profile-S compliant IP cameras |
| Video Codec | H.265 |
Storage
| Storage | 1 x 2.5" SATA anti-vibration removable HDD caddy; 1TB supplied |
Compatibility
| Control Interface | Standalone network video recorder; view/control via web browser or app (no IrisControl chart-plotter app) |
Video Output
| Output | 1 x HDMI (high definition); optional HDMI2IP encoding for non-HDMI plotters |
Connectivity
| Network | RJ45 camera network plus RJ45 for IrisControl/MFD network |
| Remote Access | WiFi and remote P2P |
| USB Touch | USB touch control for supported MFDs |
Power
| Power | +12VDC to +24VDC, <2A @ 12VDC |
Environmental
| Operating Temperature | -10C to +55C |
Physical
| Dimensions | 330 x 285 x 150 mm |
