Victron BlueSolar PWM-Pro 12/24V 20A
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron BlueSolar PWM-Pro is an affordable pulse width modulation (PWM) solar charge controller for 12V and 24V systems. It automatically detects the system voltage on first connection and regulates solar charging through a fully programmable three stage algorithm, keeping flooded, GEL or AGM batteries in good health on boats, campervans and off-grid installations.
This 20A model suits a larger panel or a modest multi-panel array. A load output with adjustable low voltage disconnect protects the battery from deep discharge, while the programmable lighting control function makes automatic dusk-to-dawn lighting simple.
Every parameter can be adjusted from a computer using the free Victron software or through the dedicated BlueSolar Pro remote panel, and an optional external temperature sensor improves charge accuracy in changing temperatures.
PRODUCT DETAILS
- PWM charge controller for 12V or 24V systems
- Automatic system voltage detection on connection
- 20A rated charge current
- Fully programmable three stage charging (bulk, absorption, float)
- Load output with low voltage disconnect and lighting control
- Programmable via free software or the BlueSolar Pro remote panel
- Optional external battery temperature sensor
- Protected against reverse polarity, short circuit and over temperature
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Rated charge current | 20 A |
| System voltage | 12/24 V (automatic detection) |
| Controller type | PWM |
Electrical
| Charge stages | Three stage (bulk, absorption, float), fully programmable |
| Load output | Manual control plus low voltage disconnect |
Physical
| Dimensions | 160 x 82 x 48 mm |
| Protection category | IP30 |
