Victron
Victron Busbar 150A 2-Pole, 10 Screws (with Cover)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
This Victron power distribution busbar provides a single common point for connecting several DC loads or sources to the battery. Rated for a continuous 150 A, it carries two heavy current stud terminals together with a row of ten screw terminals for smaller circuits, so a positive and a negative bar can each feed a group of accessories from one tidy connection.
The busbar strip is tin-plated copper for a low resistance path, mounted on a black ABS base rated UL 94 V-0. A removable protective cover is supplied to guard against accidental short circuits and to keep the installation neat.
PRODUCT DETAILS
- Common DC distribution point for connecting multiple loads and sources
- Continuous current rating of 150 A at up to 70 VDC
- Two high current 1/4 inch (M6) stud terminals plus ten screw terminals
- Low resistance tin-plated copper busbar strip
- Black ABS base rated UL 94 V-0
- Removable protective cover included
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Continuous current | 150 A |
| Number of connections | 2 studs plus 10 screws |
| Number of poles | 2-pole |
Electrical
| Continuous current rating | 150 A at 70 VDC |
Physical
| Stud size | 1/4 inch (6.35 mm), stainless steel |
| Cover included | Yes, clear polycarbonate |
| Material | Tin-plated copper strip, ABS base |
