Victron
Victron Busbar 600A 4-Pole (with Cover)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
This Victron busbar provides a single common point for connecting several DC loads or sources to the battery. Rated for a continuous 600 A at up to 70 VDC, it carries four high current stud terminals together with eight smaller screw terminals, so heavy cables and lighter accessory circuits can share one low resistance connection.
The busbar itself is tin-plated copper (19 x 24 mm), mounted on a black ABS base rated UL 94 V-0, with a black ABS protective cover supplied to guard against accidental short circuits.
PRODUCT DETAILS
- Common DC distribution point for connecting multiple loads and sources
- Continuous current rating of 600 A at up to 70 VDC
- Four 3/8 inch (9.53 mm) stainless steel high current studs
- Eight additional low current screw terminals for lighter circuits
- Low resistance tin-plated copper busbar (19 x 24 mm)
- Protective cover included
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Continuous current | 600 A |
| Number of connections | 4 studs plus 8 screws |
| Number of poles | 4-pole |
Electrical
| Continuous current rating | 600 A at 70 VDC |
Physical
| Stud size | 3/8 inch (9.53 mm), stainless steel, torque 20 Nm |
| Cover included | Yes, black ABS |
| Dimensions | 65 x 216 x 86 mm (H x W x D, with cover) |
| Material | Tin-plated copper, ABS base |
