Victron SmartSolar MPPT 100/20 (Clearance)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron SmartSolar MPPT 100/20 is a versatile solar charge controller for 12V, 24V and 48V battery banks, with Bluetooth built in for wireless set-up and monitoring via the VictronConnect app. Ultra-fast Maximum Power Point Tracking maximises energy harvest from the solar array, and a load output with low-voltage disconnect protects the battery from deep discharge. It suits a wide range of off-grid, marine and mobile installations.
Charging is managed by a multi-stage adaptive algorithm with internal temperature compensation, and usage trends are stored for review in the app. Note that on 48V systems the load output is rated at 1A. This unit is offered as a clearance item at a reduced price; it is supplied brand new with the full Victron five-year warranty.
PRODUCT DETAILS
- Built-in Bluetooth for set-up and monitoring via VictronConnect
- Ultra-fast Maximum Power Point Tracking for maximum energy harvest
- Works with 12V, 24V and 48V batteries (auto detect 12/24V)
- Rated charge current 20A; maximum PV open circuit voltage 100V
- Load output with low-voltage disconnect (1A on 48V systems)
- Clearance item, brand new with full five-year warranty
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Battery voltage | 12/24/48V (auto select 12/24V) |
| Maximum PV open circuit voltage | 100 V |
| Rated charge current | 20 A |
| Nominal PV power, 12V | 290 W |
| Nominal PV power, 24V | 580 W |
| Nominal PV power, 48V | 1160 W |
| Maximum PV short circuit current | 20 A |
| Maximum efficiency | 98 % |
Charging
| Charge voltage 'absorption' | 14.4 V / 28.8 V / 57.6 V (adjustable) |
| Charge voltage 'float' | 13.8 V / 27.6 V / 55.2 V (adjustable) |
| Charge algorithm | Multi-stage adaptive |
| Temperature compensation | -16 mV/°C (12V), -32 mV/°C (24V) |
| Self-consumption | 26 / 20 / 19 mA (12/24/48V, load on) |
| Load output | Yes, 20 A (12/24V), 1 A (48V), with automatic low-voltage disconnect |
Connectivity & control
| Bluetooth | Yes, built in |
| Data communication port | VE.Direct and Bluetooth |
Protection
| Protection | Output short circuit, over temperature |
Environmental
| Operating temperature | -30 to +60°C (full rated output up to 40°C) |
| Humidity | 95%, non-condensing |
Physical
| Colour | Blue (RAL 5012) |
| Power terminals | 6 mm² / AWG10 |
| Protection category | IP43 (electronics), IP22 (connection area) |
| Weight | 0.65 kg |
| Dimensions (h x w x d) | 100 x 131 x 60 mm |
Conformance
| Safety | EN/IEC 62109-1, UL 1741, CSA C22.2 |
