EGIS
EGIS Sealed 12-Position Ground Busbar, 200A, M8 (Bulk Pack)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The EGIS 2012B is a sealed CT Series busbar with twelve circuit positions and a high-amp M8 stud, rated to 200A total. It is most often used as a ground-return block but can equally distribute positive power, improving the robustness of connections that would otherwise be exposed to corrosion or shorting on open busbars, and allowing individual circuits to be pulled and tested for inspection or diagnosis.
The sealed unit (IP67 / IP6K9K) uses a plug-in connector, tin-plated copper-alloy conductors and stainless steel hardware, with high-temperature materials suitable for mounting almost anywhere on a vehicle or vessel. It is ignition protected, carries 22A per terminal, and offers two mounting orientations for a very compact footprint.
PRODUCT DETAILS
- 12 sealed circuit positions with M8 stud
- 200A total capacity, 22A per terminal
- Sealed to IP67 / IP6K9K against water and corrosion
- Ignition protected for enclosed petrol installations
- Tin-plated copper alloy with stainless steel hardware
- Two mounting orientations for a compact footprint
- Suits ground-return or positive distribution
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Electrical
| Max Total Current | 200 A |
| Max Terminal Current | 22 A |
| Cable Size for Max Current | 2/0 AWG |
| Max Cable Size | 4/0 AWG |
Mechanical
| Positions | 12 |
| Stud Size | M8 |
| Operating Temperature | -40 to 125 C |
| Ingress Protection | IP67 / IP6K9K |
| Ignition Protected | Yes |
