EGIS Medium Duty 30A Circuit Breaker, Push Button
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The EGIS 4712 is a panel-mount medium duty circuit breaker that combines automatic over-current protection with manual on/off switching. Rated at 30A and 32 VDC, it uses a trip-free, push-to-reset mechanism and meets ABYC E-11 interrupt requirements, making it well suited to demanding marine and mobile electrical panels.
The breaker is CE marked and made in the USA from high quality components. A compact footprint allows several units to be installed close together for high panel density, while anti-rotation, corrosion-resistant locking hardware and a 10-32 threaded mounting stud ensure a secure, long-lasting fit. It withstands an inrush rating of 35 times its current rating at half a cycle and offers an electrical endurance of 6,000 cycles at 14 VDC.
PRODUCT DETAILS
- Push-to-reset, trip-free operation
- Rated 30A at 32 VDC
- Manual on/off switching plus automatic protection
- Meets ABYC E-11 interrupt requirements
- CE marked and made in the USA
- 10-32 threaded mounting stud with locking hardware
- 6,000 cycle electrical endurance at 14 VDC
- 1 x EGIS Medium Duty 30A panel-mount circuit breaker
- Mounting hardware
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Electrical
| Current Rating | 30A |
| Voltage Rating | 32 VDC max |
| Interrupt Capacity | Meets ABYC E-11 interrupt requirements |
Mechanical
| Mounting | Panel mount, 10-32 threaded stud |
| Ingress Protection | SAE J1428 |
| Reset Type | Push-to-reset, trip-free |
