EGIS XD Flex L Lithium ACR + Relay Dual 500A 12/24V (DTM)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The EGIS 8620-6350 is a dual-circuit XD Series Flex L module that combines a lithium-tuned automatic charging relay (ACR) with a programmable relay in a single compact unit, replacing two individual high-amp relays and the external link cables between them. Built on the XD bi-stable solenoid platform, it is rated at 500A continuous with up to 1500A cranking over an 8-36V DC range, with charge and discharge thresholds suited to modern lithium battery systems. The ACR shares charge between banks automatically while the second relay handles load switching, easily replicating common dual-battery switching and charge-management layouts.
This version terminates in a sealed 6-position Deutsch DTM connector rather than flying wires, giving a clean plug-and-play installation. Each circuit has its own front-facing 3-position manual override knob that forces the relay open or closed and can be locked in either state, with a clear front LED and a remote LED that mirrors it. The sealed enclosure is rated to IP67/IP6K9K with an integrated Gore-Tex vent for long life in harsh environments, and stainless-steel studs with self-locking flanged nuts accept 1/4-20 or M6 hardware. Functions are configured via dip switches under the included protective cover, and off-state draw is just 1.3mA.
PRODUCT DETAILS
- Dual-circuit module combining a lithium-tuned ACR and a programmable relay
- Sealed 6-position Deutsch DTM connector for plug-and-play installation
- 500A total continuous current and 1500A maximum cranking current
- Wide 8-36V DC operating range for 12V and 24V systems
- Ultra-low 1.3mA off-state draw via advanced bi-stable solenoid design
- Individual 3-position manual override knobs lock each relay open or closed
- Front and remote LED status indication, programmable via dip switches
- Sealed to IP67/IP6K9K with integrated Gore-Tex vent and stainless studs (1/4-20 / M6)
- 1 x EGIS 8620-6350 dual XD Flex L module (ACR + relay) with 6-position Deutsch DTM connector
- 2 x 3-position manual override knobs (fitted)
- Protective terminal cover
- 40-circuit weatherproof label sheet
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Electrical
| Continuous Current | 500 A |
| Max Cranking Current | 1500 A |
| Voltage Range | 8 - 36 V DC |
| Off-State Current Draw | 1.3 mA |
| State Change Current | 5A @ 12V DC / 3A @ 24V DC |
Mechanical
| Mechanical Switching Life | 1,000,000 cycles |
| Connector | Deutsch DTM (6-position) |
| Ingress Protection | IP67 / IP6K9K |
