Description
The EGIS Power Post in its M10 (3/8 inch) form provides a single large stud on a robust insert-molded base, giving a common high-current connection point for joining the heaviest cable terminations. The tin-plated copper construction delivers minimal voltage drop, and the maximum amperage is determined by the attached cables.
Flexible mounting hole provisions accept #10 (M5) and 1/4 inch (M6) screws, and stainless steel self-locking hardware ensures long-term reliability. The profile is FLEX system height compatible for connection to other EGIS FLEX components.
PRODUCT DETAILS
- Single M10 (3/8 inch) stud
- Insert-molded stud connection for durability
- Tin-plated copper for minimal voltage drop
- Amperage limited only by attached cables
- Flexible #10 (M5) and 1/4 inch (M6) mounting
- Stainless steel self-locking hardware
- FLEX system height compatible
- Power Post, M10 (3/8 inch)
- Stainless steel terminal hardware
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Electrical
| Maximum Voltage | 80Vdc |
| Maximum Amperage | Based on attached cables |
Mechanical
| Stud | M10 (3/8 inch) |
| M10 Nut Torque | 120 in-lbs (13.6 N-m) recommended, 140 in-lbs (15.8 N-m) max |
| Mounting Holes | #10 (M5) and 1/4 inch (M6) |
| Material | Tin-plated copper |
General
| FLEX System Compatible | Yes |
No videos available for this product.
What stud size is fitted?
M10 (3/8 inch).
What current can it carry?
The maximum amperage is determined by the attached cables, not the post itself.
What torque should the stud nut be set to?
120 in-lbs (13.6 N-m) recommended, up to 140 in-lbs (15.8 N-m) maximum.
Is it compatible with the EGIS FLEX system?
Yes, it is FLEX system height compatible.
