EGIS Programmable ACR Automatic Charging Relay 160A 12V | 7610
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The EGIS 7610 is a TH3-Series automatic charging relay (ACR) rated at 160A continuous for 12V electrical systems. It automatically combines a start and auxiliary battery when a charge source is present, then isolates them once charging stops, so the engine-start battery is always protected from being drained by house loads.
An ultra-low off-state current draw of 1.3mA (versus 7-10mA on typical ACRs) means it will not deplete batteries during extended downtime. A sealed enclosure, stainless-steel hardware and high-temperature materials allow mounting almost anywhere, while integrated thermal-overload protection and an optional shorted-cell lock-out guard the system against cascading faults. Programmable voltage thresholds are set via top-side dip switches, and LED diagnostics report relay, voltage and start-isolation status. The unit ships with a Deutsch/Amphenol DTM connector harness and also accepts Molex MX-150 and direct wire-lead connections.
PRODUCT DETAILS
- 160A continuous current rating for 12V systems
- Automatic combine and isolate to protect the start battery
- Ultra-low 1.3mA off-state current draw
- Programmable voltage thresholds via top-side dip switches
- LED diagnostics for relay, voltage and start-isolation status
- Sealed construction with stainless-steel self-locking hardware
- Integrated thermal-overload protection and shorted-cell lock-out
- Supplied with Deutsch DTM connector harness (MX-150 and wire-lead options)
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Electrical
| Continuous Current | 160 A |
| Voltage Range | 8-18 V DC |
| Interrupt Current | 240 A |
| Off-State Current Draw | 1.3 mA |
| ACR Closing Voltage | 12.9-13.6 V DC |
| ACR Opening Voltage | 12.1-12.8 V DC |
