Description
The EGIS 40A mini ISO relay is a sealed, automotive grade changeover relay that drops straight into standard mini ISO sockets and legacy electrical systems. With Form C normally open and normally closed contacts and a 12V coil, it handles general accessory and control switching at up to 40A continuous, rated to 100,000 switching cycles.
Sealed construction and an IP54 rating give long, reliable service in demanding conditions, and the relay carries a wide temperature rating with enhanced vibration and shock protection. A vertically aligned, reinforced mounting tab eases installation, numbered terminals simplify normally open and normally closed wiring, and zinc-plated quarter-inch spade terminals accept female crimp connectors or a five-pin relay socket.
PRODUCT DETAILS
- 40A continuous current rating at 85C
- Form C normally open and normally closed contacts
- 12V coil, maximum contact voltage 75 Vdc
- 100,000 cycle electrical endurance
- Sealed construction with IP54 ingress protection
- Quarter-inch spade terminals for sockets or crimps
- Numbered terminals for easy NO/NC wiring
- 40A mini ISO relay
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Electrical
| Rated Current | 40 A at 85C |
| Max Continuous Current | 40 A |
| Maximum Contact Voltage | 75 V DC |
| Rated Coil Voltage | 12 V DC |
| Contact Arrangement | Form C (NO/NC) |
| Electrical Endurance | 100,000 cycles |
Mechanical
| Ambient Temperature Rating | -85C to 125C |
| Ingress Protection | IP54 |
| Terminals | Quarter-inch spade |
