Description
The EGIS RT Series Fuse Block protects up to six independent branch circuits using standard ATO/ATC blade fuses rated from 1 to 40 amps, with each circuit carrying up to 30 amps and the entire block rated to 100 amps. Designed for 12 and 24V DC systems with a 60V DC maximum, it supports SAE circuit protection standards for thermal and short-circuit events. High-temperature materials and stainless steel self-locking hardware allow the block to be mounted anywhere on a vehicle or vessel and to resist loosening under vibration.
An easy-to-use latching cover protects the terminals and cable edges from inadvertent shorts and keeps fuses serviceable, while included circuit identification labels make fuse diagnosis straightforward. Two jumpers are supplied to bridge circuits to a common feed where required. Designed and made in the U.S.A.
PRODUCT DETAILS
- Six independent ATO/ATC blade-fuse circuits
- Accepts fuses from 1 to 40A, up to 30A per circuit
- 100A maximum for the entire block
- 12/24V DC nominal, 60V DC maximum
- Supports SAE circuit protection standards
- Latching protective cover with included circuit labels
- Stainless steel self-locking hardware and two jumpers
- RT Series 6-circuit fuse block
- Protective latching cover
- Two jumpers
- Circuit identification labels
- Stainless steel self-locking hardware
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Electrical
| Continuous Current per Circuit | 30A |
| Maximum Current (entire block) | 100A |
| Fuse Type | ATO / ATC (1 to 40A) |
| Nominal Voltage | 12/24V DC |
| Maximum Voltage | 60V DC |
Mechanical
| Circuits | 6 independent |
| Hardware Material | Stainless steel self-locking |
| Cover | Latching protective cover |
