EGIS XD Flex 2 Relay/ACR Single 500A 12/24V (No Knob)

£192.16
Tax included.
8710-1600
Single-circuit XD Series Flex 2 bi-stable relay for 12V and 24V systems, configurable as a switched relay or automatic charging relay via dip switches. Rated 500A continuous and 1500A cranking with a 1.3mA off-state draw and sealed IP67 / IP6K9K construction. Wire-for-wire compatible with Blue Sea ML-Series solenoids and remote battery switches; supplied with tinned wire leads and no manual override knob.
✓ Collection or delivery in 1-2 weeks

Pickup available at Mercury Yacht Harbour

Usually ready in 2-4 days

Description

The EGIS XD Flex 2 single solenoid is a high-current bi-stable relay for 12V and 24V DC systems that serves as an improved replacement for legacy solenoids and remote battery switches. It is wire-for-wire compatible with Blue Sea ML-Series solenoid and ML remote battery switch products, and can be set through dip switches to operate as a basic switched relay or as an automatic charging relay. It carries 500A continuously and up to 1500A during cranking across an 8 to 36V DC range.

Construction is sealed to IP67 and IP6K9K with high-temperature electronics, an integrated Gortex vent and forward-facing stainless steel cable-lug studs that accept 1/4-20 or M6 hardware and make landing large cables easy. The bi-stable solenoid draws just 1.3mA in the off state, a front-facing LED reports status with a remote LED replica output, and the dip switches sit under an included protective cover with label recesses. This version ships with tinned wire leads and no manual override knob.

PRODUCT DETAILS

  • High-current single-circuit bi-stable relay, configurable as relay or ACR via dip switches
  • Wire-for-wire compatible with Blue Sea ML-Series solenoids and remote battery switches
  • 500A continuous and 1500A cranking rating for 12V and 24V systems
  • Ultra-low 1.3mA off-state current draw
  • Sealed IP67 / IP6K9K construction with integrated Gortex pressure vent
  • Forward-facing stainless steel cable-lug studs accepting 1/4-20 / M6 hardware
  • Front-facing status LED with remote LED replica output
  • EGIS XD Series Flex 2 single-circuit relay with tinned wire leads
  • Protective terminal cover
  • Stainless steel studs and self-locking flanged nuts

No compatible transducers listed for this product.

No spares or accessories listed for this product.

No compatible products found.

Electrical

Total Continuous Current500 A
Max Cranking Current1500 A
Voltage Range8-36 V DC
Off-State Current Draw1.3 mA
State Change Current5A @ 12V DC / 3A @ 24V DC

Mechanical

Mechanical Switching Life1,000,000 cycles
ConnectorTinned wire leads
Ingress ProtectionIP67 / IP6K9K

No videos available for this product.

Can this replace a Blue Sea ML solenoid or remote battery switch?
Yes. It is designed as an improved replacement for legacy solenoids and remote battery switches and is wire-for-wire compatible with Blue Sea ML-Series solenoid and ML remote battery switch products.
Can it work as an automatic charging relay?
Yes. The single circuit is configurable via dip switches to operate as a basic switched relay or as an automatic charging relay that combines and isolates battery banks.
What voltage systems and current does it support?
It operates across 8 to 36V DC, suiting both 12V and 24V systems, and is rated for 500A continuous current with up to 1500A during engine cranking.
How does it wire into the system?
Forward-facing stainless steel cable-lug studs accept 1/4-20 or M6 hardware for the main power cables, while control connections are made through the tinned wire leads. This model has no manual override knob.
