EGIS XD Programmable Low Voltage Disconnect Relay 500A Tinned Wires

£224.51
Tax included.
8710-1800
Single-circuit XD programmable low voltage disconnect (LVD) relay rated 500 A continuous, supplied with tinned flying wires and no manual override knob for lever-free installations.
✓ Collection or delivery in 1-2 weeks

Pickup available at Mercury Yacht Harbour

Usually ready in 2-4 days

Description

The XD programmable low voltage disconnect relay protects starting capacity by shedding non-essential loads the moment battery voltage falls to a configurable set-point, eliminating the weak-start and no-start conditions that result from an exhausted main battery. Built on the XD bi-stable solenoid platform, it switches 500 A continuously and up to 1,500 A cranking while drawing just 1.3 mA in the off state, and a front-facing LED reports relay status with optional remote LED replication. The low voltage cut-out point is set quickly using the DIP switches under the protective cover, with a configuration guide printed on the reverse.

This version ships with tinned flying wires and no manual override knob, making it ideal for permanent OEM installations where lever-free operation is preferred. The case is sealed to IP67 and IP6K9K with high-temperature electronics and an integrated Gore-Tex vent, so it withstands harsh marine and mobile environments, while stainless steel studs and large 1/4-20 / M6 mounting holes keep installation straightforward. A protective terminal cover and a 40-circuit waterproof label sheet are included, and the relay can be expanded with 8790 and 8791 link bars alongside other XD units.

PRODUCT DETAILS

  • Programmable low voltage disconnect protects starting capacity by shedding loads at a set voltage
  • DIP-switch configurable cut-out set-point with guide printed under the protective cover
  • 500 A continuous and 1,500 A cranking switching with only 1.3 mA off-state draw
  • Lever-free design with no manual override knob, supplied with tinned flying wires
  • Front-facing LED status display with optional remote LED replication
  • Sealed to IP67 and IP6K9K with integrated Gore-Tex vent and stainless steel hardware
  • Expandable with 8790 and 8791 link bars to integrate with other XD relays
  • XD single-circuit low voltage disconnect relay with pre-fitted tinned flying wires
  • Protective terminal cover with circuit label recesses
  • 40-circuit waterproof label sheet
  • 18-8 stainless steel studs and self-locking flanged nuts

No compatible transducers listed for this product.

No spares or accessories listed for this product.

No compatible products found.

Electrical

Continuous Current500 A
Max Cranking Current1,500 A
Voltage Range8-36 V DC
Off-State Current Draw1.3 mA
State Change Current5A at 12 Vdc / 3A at 24 Vdc
Relay FunctionProgrammable low voltage disconnect (LVD)

Mechanical

Circuit ConfigurationSingle circuit
Mechanical Switching Life1,000,000 cycles
Ingress ProtectionIP67 / IP6K9K
Manual OverrideNone (lever-free)
ConnectorTinned flying wires
Mounting Hardware1/4-20 / M6 holes; 18-8 stainless steel studs, self-locking flanged nuts

No videos available for this product.

What problem does a low voltage disconnect solve?
It disconnects non-essential loads once battery voltage drops to a programmable set-point, preserving enough charge to crank the engine and preventing weak-start or no-start conditions caused by an exhausted main battery.
How is the disconnect voltage set?
The cut-out set-point is selected using the DIP switches located under the protective cover. A configuration guide printed on the reverse of the cover walks you through the available settings.
Does this version have a manual override knob?
No. This is the lever-free model with no override knob, supplied with tinned flying wires, which suits permanent OEM and installer applications.
Can it be installed in any orientation and environment?
Yes. The sealed IP67 / IP6K9K construction, high-temperature electronics and integrated Gore-Tex vent allow it to be mounted in exposed and harsh locations.
