Victron
Victron MEGA Fuse 200A (58V)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
This Victron MEGA fuse is a high-current, bolt-down blade fuse for protecting heavy DC power circuits such as battery-to-inverter, battery-to-busbar and main distribution feeds. Its compact, low-profile body and stud connections suit the tight, high-vibration spaces found on boats and in vehicles.
This 200A version is rated for systems up to 58 volts, making it suitable for 12V, 24V and 48V installations. It has a slow-blow characteristic that tolerates normal inrush currents while protecting cabling and equipment against short circuits and sustained overloads. It mounts into a MEGA fuse holder using M8 studs for a secure, low-resistance connection.
PRODUCT DETAILS
- Rated 200A for high-current DC circuit protection
- Rated for systems up to 58 volts, suits 12V, 24V and 48V
- Slow-blow characteristic tolerates normal inrush and surge currents
- Bolt-down blade design with M8 studs for a secure, low-resistance connection
- Compact, low-profile body ideal for tight marine and vehicle installations
- Fits a standard MEGA fuse holder
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Key specifications
| Rated current | 200 A |
| Maximum voltage | 58 V |
| Fuse type | MEGA (slow-blow, bolt-down) |
Electrical
| Breaking capacity | High DC breaking capacity |
Physical
| Stud / mounting | M8 stud (fits MEGA fuse holder) |
