Victron GX IO-Extender 150
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron GX IO-Extender 150 adds more inputs, outputs and relays to a GX device such as the Cerbo GX or Ekrano GX. It connects over USB, which also powers it, making it a simple way to expand a system's IO for signalling and control.
It provides eight digital IOs (configurable in two sets of four as inputs or outputs), four PWM ports for device regulation, and two latching relays that hold their state even if power is lost. It is fully supported in Venus OS Node-RED, and outputs and relays can be controlled from the GX screen or remotely through the VRM portal. Note that the digital outputs are for signalling and must not be used to switch loads directly.
PRODUCT DETAILS
- Adds inputs, outputs and relays to a GX device
- Works with Cerbo GX, Ekrano GX and other GX devices
- Eight digital IOs configurable as inputs or outputs
- Four PWM ports plus two latching relays that hold state on power loss
- USB connected and USB powered
- Fully supported in Venus OS Node-RED and controllable via VRM
