Mastervolt DC Master Voltage Converter (Non-Isolated / 12V - 24V, 7A)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The DC Master 12/24-7 is a non-isolated DC-DC converter that steps a 12 V battery system up to a stable 27.2 V output, supplying up to 7 A continuously to equipment that requires 24 V. It is intended for recreational and semi-professional installations where the main system runs at 12 V but certain consumers need a reliable 24 V supply.
As a non-isolated model there is a direct electrical connection between the input and output, which keeps costs and heat generation low. It is well suited to systems with negative earthing. The converter also provides two minutes of extra capacity, delivering up to 9 A for short intervals when a brief power boost is needed.
The unit is stabilised, naturally cooled and rated to IP53. It is delivered complete with a mounting bracket, screws and fasteners for quick installation.
PRODUCT DETAILS
- Non-isolated 12 V to 24 V step-up DC-DC converter with direct input/output connection
- Stabilised 27.2 V output at 7 A continuous
- Two minutes of extra capacity up to 9 A for short power boosts
- Low heat generation and high efficiency
- Suited to systems with negative earthing
- IP53 protection with natural cooling
- Supplied with mounting bracket, screws and fasteners
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
General
| Nominal input voltage | 12 V |
| Input voltage range (max.) | 10-15.5 V DC (16 V) |
| Nominal output voltage | 27.2 V |
| Continuous output current | 7 A |
| Max. output current (for 2 min. intervals) | 9 A |
| Nominal output power | 191 W |
| Max. output power | 245 W |
| Galvanic isolation | No |
| Stabilised | Yes |
| Compliance | CE |
Technical
| DC consumption | < 25 mA |
| Connections | Fast-on |
| Temperature range (ambient temp.) | -25 °C to 80 °C, derating > 30 |
| Cooling | Natural cooling |
| Protection degree | IP53 |
Physical
| Dimensions (H x W x D) | 167 x 87 x 50 mm |
| Weight | 0.64 kg |
