Victron Orion-Tr Smart 12/24-15 (360W) Non-Isolated DC-DC Charger
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Orion-Tr Smart 12/24-15 steps a 12V supply up to charge a 24V service battery at up to 15A (360W continuous at 40 degrees C). Its wide 8 to 17V input and buck-boost design hold the output steady even when the source voltage drops, a frequent situation on boats and vehicles fitted with a Euro 5 or Euro 6 smart alternator or where long cable runs cause voltage loss.
An adaptive three-stage charge algorithm (bulk, absorption, float) suits both lead-acid and lithium batteries, shortening the absorption phase after a shallow discharge and lengthening it after a deep one so the battery is fully recharged without being overcharged. Engine-running detection guards the input battery against discharge, and the converter can instead be set as a fixed-voltage power supply. Built-in Bluetooth provides monitoring, configuration and firmware updates through the VictronConnect app.
The unit is short-circuit proof, can be paralleled in unlimited numbers to increase output, and carries IP43 protection for the electronics when installed with the screw terminals facing down. A remote on/off input is fitted and installation needs no special tools.
PRODUCT DETAILS
- 12V to 24V non-isolated charging at up to 15A (360W continuous at 40 degrees C)
- Built-in Bluetooth for monitoring, settings and updates via VictronConnect
- Adaptive three-stage charge algorithm (bulk, absorption, float)
- Suitable for both lead-acid and lithium batteries
- Wide 8 to 17V input with buck-boost for stable output on smart alternators
- Engine-running detection protects the starter battery
- Can also be configured as a fixed-voltage power supply
- Short-circuit proof, parallelable and IP43 rated
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Key specifications
| Input voltage range | 8 to 17 V |
| Output voltage (nominal) | 24.2 V |
| Continuous output current | 15 A at 40 degrees C |
| Continuous output power | 360 W at 40 degrees C |
| Galvanic isolation | Non-isolated |
| Bluetooth | Yes |
| Protection category | IP43 (electronic components) |
Input
| Input voltage range | 8 to 17 V |
| Under-voltage shut down | 7 V |
| Under-voltage restart | 7.5 V |
| No load input current | < 100 mA |
| Standby current | Less than 1 mA |
Output
| Nominal output voltage | 24.2 V |
| Output voltage adjust range | 18 to 30 V |
| Output voltage tolerance | +/- 0.2 V |
| Output noise | 2 mV rms |
| Continuous output current at 40 degrees C | 15 A |
| Maximum output current (10 s) | 25 A |
| Short circuit output current | 40 A |
| Continuous output power at 25 degrees C | 430 W |
| Continuous output power at 40 degrees C | 360 W |
| Maximum efficiency | 88 % |
Charger
| Charge algorithm | 3-stage adaptive (bulk, absorption, float) |
| Battery types | Lead-acid and lithium |
| Maximum charge current | 15 A |
| Engine shutdown detection | Yes |
| Can be used as power supply | Yes, output voltage set with Bluetooth |
| VE.Direct port | No |
General
| Remote on/off | Yes |
| Parallel operation | Yes, unlimited units |
Environmental
| Operating temperature range | -20 to +55 degrees C (derate 3 % per degree C above 40) |
| Humidity | Max. 95 % non-condensing |
Physical
| DC connection | Screw terminals |
| Maximum cable cross-section | 16 mm2 (AWG6) |
| Weight | 1.8 kg |
| Dimensions (h x w x d) | 130 x 186 x 80 mm |
| Protection category | IP43 (electronics), IP22 (connection area) |
Conformance
| Safety | EN 60950 |
| Emission | EN 61000-6-3, EN 55014-1 |
| Immunity | EN 61000-6-2, EN 61000-6-1, EN 55014-2 |
| Automotive Directive | ECE R10-5 |
