Victron Orion-Tr 24/12-5 (60W) Non-Isolated DC-DC Converter
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Orion-Tr 24/12-5 is a compact non-isolated DC-DC converter that steps a 24V supply down to a regulated 12.7V output, delivering up to 5A (60W continuous). It is intended to run 12V equipment from a 24V system rather than to charge a battery; where controlled battery charging is required, an Orion-Tr Smart charger should be used instead.
Synchronous rectification gives a high full-load efficiency of around 95 percent, which keeps heat and current draw low. The converter holds a stable output across its 18 to 35V input range and is fully protected, making it well suited to powering electronics, lighting and other 12V loads aboard boats, in vehicles and in off-grid installations.
Housed in a small enclosure with screw terminals, the unit installs without special tools and carries IP43 protection for the electronics when mounted with the terminals facing downwards.
PRODUCT DETAILS
- 24V to 12V non-isolated conversion at up to 5A (60W continuous)
- Regulated 12.7V output for running 12V equipment from a 24V system
- High full-load efficiency of around 95 percent via synchronous rectification
- Wide 18 to 35V input range
- Compact enclosure with screw terminals, no special tools needed
- IP43 protection when terminals face downwards
- Not intended for battery charging; use an Orion-Tr Smart for charging
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Input voltage range | 18 to 35 V |
| Output voltage (nominal) | 12.7 V |
| Continuous output current | 5 A |
| Continuous output power | 60 W |
| Galvanic isolation | Non-isolated |
| Bluetooth | No |
| Protection category | IP43 |
Input
| Input voltage range | 18 to 35 V |
| Off load current | < 20 mA |
Output
| Output voltage | 12.7 V |
| Continuous output current | 5 A |
| Maximum output current | 7 A |
| Maximum efficiency | 95 % |
General
| Galvanic isolation | No |
Environmental
| Operating temperature range | -20 to +55 degrees C (derate 3 % per degree C above 40) |
Physical
| DC connection | Screw terminals |
| Maximum cable cross-section | 3.3 mm2 (AWG12) |
| Weight | 0.09 kg |
| Dimensions (h x w x d) | 53 x 51 x 27 mm |
| Protection category | IP43 |
Conformance
| Safety | EN 60950 |
| Emission | EN 61000-6-3, EN 55014-1 |
| Immunity | EN 61000-6-2, EN 61000-6-1, EN 55014-2 |
| Automotive Directive | ECE R10-6 |
