Victron Orion-Tr 24/48-8,5 (400W) Isolated DC-DC Converter
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Orion-Tr 24/48-8,5 is an isolated DC-DC converter rated at 400W continuous, converting a 16-35 V input into a nominal 48.2 V output. The output voltage is adjustable across 40-60 V, and galvanic isolation of 200V DC is provided between the input, output and case, which makes it suitable for systems where the input and output grounds must be kept separate.
All models are short circuit proof and protected against over temperature, with the output current reducing progressively at high ambient temperatures. A remote on/off terminal removes the need for a high current switch in the input wiring and can be operated by a low power switch or, for example, an engine run/stop signal. The unit is rated to IP43 when installed with the screw terminals facing downwards, and an unlimited number of units can be connected in parallel to increase the available output current.
The output voltage is adjustable and the Orion-Tr converter is not intended for battery charging. Where a regulated charge profile is required, use an Orion-Tr Smart DC-DC charger instead.
PRODUCT DETAILS
- Isolated DC-DC converter rated 400W continuous (48.2 V nominal output)
- Input voltage range 16-35 V with buck-boost regulation
- Adjustable output voltage across 40-60 V
- 200V DC galvanic isolation between input, output and case
- Short circuit proof with high temperature output current reduction
- Remote on/off terminal for low current or engine run/stop switching
- Screw terminal connections, no special tools required for installation
- IP43 rated and parallelable for higher output current
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Input voltage range | 16-35 V |
| Output voltage (nominal) | 48.2 V |
| Continuous output current | 8.5 A at 48.2 V output and 40 degrees C |
| Continuous output power | 400 W at 40 degrees C |
| Galvanic isolation | Isolated (200V DC between input, output and case) |
| Bluetooth | No |
| Protection category | IP43 (screw terminals oriented downwards) |
Input
| Input voltage range | 16-35 V |
| Under voltage shut down | 14 V |
| Under voltage restart | 15 V |
| No load input current | < 120 mA |
| Current consumption (remote off) | < 200 uA when disabled via remote port |
| Input fuse | Fitted (not replaceable) on 12V and 24V input models |
Output
| Nominal output voltage | 48.2 V |
| Output voltage adjustment range | 40-60 V |
| Output voltage tolerance | +/- 0.2 V |
| Output noise | 2 mV rms |
| Continuous output current | 8.5 A at 48.2 V output and 40 degrees C |
| Maximum output current (10 s) | 15 A |
| Short circuit output current | 25 A |
| Continuous output power at 25 degrees C | 480 W |
| Continuous output power at 40 degrees C | 400 W |
| Maximum efficiency | 89 % |
General
| Galvanic isolation | 200V DC between input, output and case |
| Remote on/off | Yes |
| Protection | Short circuit proof, output current reduction at high temperature |
| Parallel operation | Yes, unlimited number of units |
Physical
| DC connection | Screw terminals |
| Maximum cable cross-section | 16 mm2 (AWG6) |
| Weight | 1.6 kg (3.5 lb) |
| Dimensions (h x w x d) | 130 x 186 x 70 mm (5.1 x 7.3 x 2.8 inch) |
Environmental
| Operating temperature range | -20 to +55 degrees C (derate 3 % per degree C above 40 degrees C) |
| Humidity | Max. 95 % non-condensing |
| Protection category | IP43 (screw terminals oriented downwards) |
Conformance
| Safety | EN 60950 |
| Emission | EN 61000-6-3, EN 55014-1 |
| Immunity | EN 61000-6-2, EN 61000-6-1, EN 55014-2 |
| Automotive Directive | ECE R10-5 |
