Victron Phoenix Smart IP43 Charger 24/25 (1+1)
£469.20
/
Tax included.
PSC242551095
The Victron Phoenix Smart IP43 Charger 24/25 (1+1) is a 24V 25A mains charger with built-in Bluetooth, a 6-stage adaptive charge algorithm and lithium compatibility. The 1+1 version adds a 4 A output to keep a starter battery topped up.
✓
Collection or delivery in 1-2 weeks
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Phoenix Smart IP43 Charger is Victron Energy's compact, natural-convection cooled mains charger with built-in Bluetooth. It suits marine, leisure, eMobility and off-grid systems where a quiet, efficient charger that can be set up and monitored from a phone is wanted.
This 24V 25A model uses an adaptive 6-stage charge algorithm that optimises the charge to the way the battery is used, with selectable Normal, High and Lithium profiles and a fully programmable option. A storage mode lowers the voltage when the battery is left connected to limit gassing and corrosion.
The 1+1 output configuration charges a main house bank at the full rated current and tops up a starter battery through a second output limited to about 4 A. VE.Smart Networking allows external voltage and temperature sensing and synchronised charging across several units, and a VE.Direct port links the charger to a GX device for monitoring through the VRM portal.
PRODUCT DETAILS
- 24V 25A output with built-in Bluetooth and VictronConnect app
- Adaptive 6-stage charge algorithm with Normal, High and Lithium profiles
- Two outputs: full current to the house bank plus a 4 A starter output
- Charges lithium (LiFePO4) and lead-acid batteries
- Storage mode limits gassing and corrosion during lay-up
- Natural convection cooled, silent operation, IP43 electronics
- VE.Direct port for GX devices and VRM monitoring
- VE.Smart Networking for external sensing and synchronised charging
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Battery voltage | 24 V |
| Charge current | 25 A |
| Number of outputs | 1+1 |
| Maximum efficiency | 96 % |
Charging
| Charge algorithm | 6-stage adaptive (bulk, absorption, recondition, float, storage, refresh; 3-stage for lithium) |
| Charge voltage 'absorption' | 28.8 V (Normal mode) |
| Charge voltage 'float' | 27.6 V (Normal mode) |
| Charge voltage 'storage' | 26.4 V (Normal mode) |
| Recommended battery capacity | 125 to 250 Ah |
| Temperature compensation | -32 mV/C |
| Back current drain | <1 mA |
| Charge current starter battery | 4 A max (1+1 models only) |
Input
| AC input voltage range | 85 to 250 VAC (full power from 100 VAC, startup from 90 VAC); 90 to 375 VDC |
| Input frequency | 45 to 65 Hz |
| Power factor | 1 |
| Maximum input current setting | 3 to 10 A |
| No-load power consumption | 1 W |
Connectivity & control
| Bluetooth | Yes, built-in (-4 dBm, 2402 to 2480 MHz), VictronConnect app |
| Communication port | VE.Direct |
| Programmable relay | Yes (SPDT, 5 A up to 250 VAC / 5 A up to 28 VDC) |
| Remote on/off | Yes (2-pole terminal) |
Protection
| Protection | Battery reverse polarity (internal fuse, not user accessible), output short circuit, over temperature |
Environmental
| Operating temperature | -20 to 60 C (rated output to 40 C, derate to 20% at 60 C) |
| Humidity | Max 95% (non-condensing) |
Physical
| Colour | Aluminium, blue RAL 5012 |
| Protection category | IP43 (electronic components), IP22 (connection area) |
| Terminals | Battery screw terminals 16 mm2 (AWG6); AC IEC 320 C14 inlet with retainer clip (AC cord ordered separately) |
| Weight | 2.7 kg |
| Dimensions (h x w x d) | 180 x 249 x 116 mm |
Conformance
| Safety | EN 60335-1, EN 60335-2-29 |
| Emission / Immunity | EN 55014-1, EN 55014-2, EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-3-2, EN 61000-3-3 |
No videos available for this product.
Does this charger have Bluetooth?
Yes. The Phoenix Smart IP43 Charger has built-in Bluetooth, so you can set up, monitor and update it and configure alarms from the VictronConnect app on a phone or tablet. It can also connect by VE.Direct to a GX device such as a Cerbo GX for full system monitoring through the VRM portal.
What does the (1+1) output mean?
The 1+1 version has two outputs. The main output delivers the full rated current to your house bank, and a second output limited to about 4 A keeps a starter battery topped up.
Can it charge lithium (LiFePO4) batteries?
Yes. A dedicated lithium charge algorithm is selectable, and the charge algorithm is fully programmable over Bluetooth or VE.Direct. Charger on/off can also be driven from a lithium BMS through the remote on/off port.
Is a mains lead included?
No. The charger uses an IEC 320 C14 inlet and the AC cord with the correct country plug must be ordered separately.
Can several chargers work together?
Yes. Pairing two or more units in a VE.Smart Network enables synchronised charging, which improves charge efficiency and battery life. An external Smart Battery Sense, SmartShunt or BMV-712 can also share battery voltage and temperature with the chargers.
