Victron Blue Smart IP65 Charger 6V/12V 1.1A
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Blue Smart IP65 Charger 6V/12V 1.1A is a compact, professional grade portable battery charger for small 6 V and 12 V batteries, delivering 1.1 A of charge current from a wide-range 100 to 250 V AC supply. Water, dust and chemical resistant to IP65, it is ideal for motorcycles, jet skis, classic cars, garden equipment and other small vehicles.
An intelligent 7 stage adaptive charge algorithm optimises every recharge and looks after long term battery health, while integrated Bluetooth lets you set up the charger, choose the battery type and monitor voltage and current from your phone using the VictronConnect app. A dedicated Li-ion mode sits alongside the lead-acid presets, and a recovery function can revive batteries discharged to nearly zero volts.
A low current mode reduces the output to 0.5 A for the smallest batteries, and once charged it draws under 0.5 W. It suits batteries of roughly 20 to 50 Ah, and can maintain batteries up to 300 Ah.
PRODUCT DETAILS
- Charges both 6 V and 12 V batteries at 1.1 A, ideal for motorcycles, jet skis and small vehicles
- Wide 100 to 250 VAC input range for use worldwide
- Built-in Bluetooth for setup, battery-type selection and live monitoring via VictronConnect
- 7-stage adaptive charge algorithm with a dedicated Li-ion (LiFePO4) mode
- Low current mode reduces output to 0.5 A for the smallest batteries
- IP65 rated: splash, dust and chemical resistant for outdoor use
- Recovery function recharges batteries discharged to nearly zero volts
- Fanless and totally silent with under 0.5 W standby consumption
No compatible transducers listed for this product.
No compatible products found.
Key specifications
| Battery voltage | 6 V and 12 V |
| Charge current | 1.1 A |
| Number of outputs | 1 |
| Maximum efficiency | 82% |
Charging
| Charge algorithm | 7-stage adaptive |
| Low current mode | 0.5 A |
| Charge voltage 'absorption' | 6V: Normal 7.2 V, High 7.35 V, Li-ion 7.1 V. 12V: Normal 14.4 V, High 14.7 V, Li-ion 14.2 V |
| Charge voltage 'float' | 6V: Normal 6.9 V, High 6.9 V, Li-ion disabled. 12V: Normal 13.8 V, High 13.8 V, Li-ion disabled |
| Charge voltage 'storage' | 6V: Normal 6.6 V, High 6.6 V, Li-ion 6.75 V. 12V: Normal 13.2 V, High 13.2 V, Li-ion 13.5 V |
| Recommended battery capacity | 20 to 50 Ah (up to 300 Ah maintenance only) |
| Temperature compensation | 6V: 8 mV/°C, 12V: 16 mV/°C (lead-acid only) |
| Back current drain | 0.1 Ah/month (140 uA) |
Input
| AC input voltage range | 100 to 250 VAC |
| Input frequency | 45 to 65 Hz |
| No-load power consumption | Less than 0.5 W |
Connectivity & control
| Bluetooth | Built-in (-4 dBm, 2402 to 2480 MHz) |
| Battery type selection | Lead-acid presets and Li-ion (LiFePO4) via VictronConnect |
Protection
| Protection | Reverse polarity, output short circuit, over temperature |
Environmental
| Operating temperature | -30 to +50°C (full rated output up to 30°C) |
| Cooling | Natural convection, fanless |
| Humidity | Max 95% (non-condensing) |
Physical
| Material | Plastic enclosure |
| Protection category | IP65 (splash and dust proof) |
| Terminals | 1.5 m battery cable, 1.5 m AC cable with mains plug |
| Weight | 0.4 kg |
| Dimensions (h x w x d) | 38 x 64 x 153 mm |
Conformance
| Safety | EN 60335-1, EN 60335-2-29 |
| Emission / Immunity | EN 55014-1, EN 55014-2, EN 61000-6-1/2/3, EN 61000-3-2/3 |
