Victron GX LTE 4G
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The GX LTE 4G is a cellular modem accessory that gives any Victron GX device its own mobile internet connection. It is the 4G successor to the discontinued GX GSM, adding LTE alongside the existing 2G and 3G technologies so the system stays online in more locations and on newer networks. Once connected, the GX device reports to the Victron Remote Management (VRM) portal, allowing you to monitor and configure the installation from anywhere.
A built-in GPS receiver lets the system be tracked and geo-fenced on VRM when the optional active GPS antenna is fitted, which is useful for vessels and other mobile installations. The modem connects to the GX device over a fixed USB cable and is powered directly from the battery bank across a wide voltage range, with a small indoor antenna and a fused DC power cable supplied in the box.
An active SIM card of the Mini-SIM format is required and is not included. The unit provides an internet connection for the GX device only and does not share data with phones, tablets or laptops. For installations that need internet across several devices, a dedicated mobile router is the better choice. This is the GX LTE 4G-E variant for Europe, the Middle East, Africa, Korea and Thailand; A and SA variants cover other regions.
PRODUCT DETAILS
- Adds 2G, 3G and 4G LTE mobile internet to any Victron GX device
- The 4G successor to the discontinued GX GSM cellular modem
- Connects the GX device to the Victron Remote Management (VRM) portal for remote monitoring
- Built-in multi-constellation GPS receiver (GPS, BeiDou, GLONASS, GALILEO, QZSS) for tracking and geo-fencing
- Connects to the GX device over a fixed USB cable; no network configuration needed
- Wide 8 to 70 VDC supply, powered directly from the battery bank
- Indoor LTE antenna and fused DC power cable included; optional outdoor 4G antenna increases range
- Requires an active Mini-SIM card (not supplied); provides internet for the GX device only
No compatible transducers listed for this product.
No compatible products found.
Key specifications
| Device type | Cellular modem |
| Display | No |
| Supply voltage | 8 - 70 |
| Connectivity | 2G / 3G / 4G LTE cellular, GPS |
| Power draw | 2.5W during data transfer, <1.0W idle, +0.4W with GPS |
Electrical
| Inline fuse (included) | T3.15A 250V (5x20mm slow blow) |
| Power cable (included) | 1.4m cable with inline fuse holder, terminal block and 10mm ring terminals |
| Recommended fuse size | 500mA @ 12V / 250mA @ 24V / 100mA @ 48V |
Communication ports
| USB host ports | Fixed 1.0m cable with USB-A connector (connects to the GX device) |
Cellular & GPS
| GNSS | GPS / BeiDou / GLONASS / GALILEO / QZSS |
| Antenna connector | LTE: SMA female; GPS: SMA female |
| SIM card | Regular Mini SIM (supports both 1.8V and 3V) |
| Data transmission (max. down/up) | LTE Cat-1: 10 / 5 Mbps; 3G HSPA+: 42 / 5.76 Mbps; 2G EDGE: 236.8 / 236.8 Kbps; 2G GPRS: 85.6 / 85.6 Kbps |
| Status indicator | Blue LED |
Physical
| Dimensions (h×w×d) | 106 × 42.5 × 22 |
| Weight | 0.08 |
Operating conditions
| Operating temperature range | -40 to +50 |
