Victron Orion 110/24 (360W) 110V Isolated DC-DC Converter
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Orion 110/24 is a 110V isolated DC-DC converter rated at 360W, taking a nominal 110V DC input (60 to 140V) and delivering a regulated 24 V output. Galvanic isolation of more than 400V rms is provided between the input, output and case, suiting installations where the input and output grounds must remain separate.
The converter uses temperature-controlled fan-assisted cooling and is housed in an anodised aluminium case. It is short circuit proof and protected against overheating, reverse polarity and over voltage, the latter by a varistor that also guards against load dump. Connections are made with 6.3 mm (0.25 inch) push-on flat blade terminals.
This is a voltage converter rather than a battery charger and has no multi-stage charge algorithm. It is intended for powering DC loads from a 110V DC supply.
PRODUCT DETAILS
- Isolated 110V DC-DC converter rated 360W
- Nominal 110V DC input with a wide 60 to 140V range
- Regulated 24 V output
- Galvanic isolation greater than 400V rms between input, output and case
- Temperature-controlled fan-assisted cooling
- Short circuit proof with reverse polarity and over voltage protection
- Anodised aluminium casework
- 6.3 mm (0.25 inch) push-on flat blade connections
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Input voltage range | 110V (60-140V) |
| Output voltage (nominal) | 24 V |
| Continuous output current | 15 A |
| Continuous output power | 360 W |
| Galvanic isolation | Isolated (> 400V rms between input, output and case) |
| Bluetooth | No |
Input
| Input voltage | 110V (60-140V) |
| Off load current | < 25 mA |
Output
| Output voltage | 24 V |
| Continuous output current | 15 A |
| Output power rating | 360 W |
| Output voltage stability | 2 % |
| Output voltage tolerance | 3 % |
| Output noise | < 50 mV rms |
| Maximum efficiency | approx. 85 % |
General
| Galvanic isolation | > 400V rms between input, output and case |
| Cooling | Fan-assisted, temperature controlled |
| Overcurrent protection | Short circuit proof |
| Overheating protection | Reduction of output voltage |
| Reverse polarity protection | Fuse and reverse connected diode across input |
| Over voltage protection | Varistor (also protects against load dump) |
Physical
| Casework | Anodised aluminium |
| Connections | 6.3 mm (0.25 inch) push-on flat blade connectors |
| Weight | 1.4 kg (3.1 lb) |
| Dimensions (h x w x d) | 82 x 132 x 190 mm (3.2 x 5.2 x 7.5 inch) |
Environmental
| Operating temperature | -20 to +40 degrees C (derate linearly to 0 A at 70 degrees C) |
| Temperature rise after 30 minutes at full load | 30 degrees C |
| Humidity | Max. 95 % non-condensing |
Conformance
| Safety | EN 60950 |
| Emission | EN 61000-6-3, EN 55014-1 |
| Immunity | EN 61000-6-2, EN 61000-6-1, EN 55014-2 |
