Victron Orion 12/24-8 Non-Isolated DC-DC Converter
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Orion 12/24-8 is a non-isolated DC-DC converter that steps a 12V supply up to a fixed 24V output, delivering up to 8A (192W continuous). It is designed to power 24V equipment from a 12V system. Unlike the adjustable models in the high-power range it has a fixed output and is not intended to buffer-charge a battery; where controlled charging is needed an Orion-Tr Smart charger should be used.
The converter holds a stable output across a 9 to 18V input and is short-circuit protected, with a quiet fanless design and a low off-load current. It suits onboard, automotive and off-grid installations where a small amount of 24V power is required from a 12V source.
Connections are made with 6.3 mm Faston tabs and the supply includes four insulated female crimp terminals, so the unit installs quickly without special tools.
PRODUCT DETAILS
- 12V to 24V non-isolated conversion at up to 8A (192W continuous)
- Fixed 24V output for running 24V equipment from a 12V system
- Efficiency of around 95 percent
- Wide 9 to 18V input range
- Fanless design with low off-load current
- 6.3 mm Faston tab connections, four crimp terminals supplied
- Fixed output, not intended for battery charging
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Input voltage range | 9 to 18 V |
| Output voltage (nominal) | 24 V (fixed) |
| Continuous output current | 8 A |
| Continuous output power | 192 W (24 V x 8 A) |
| Galvanic isolation | Non-isolated |
| Bluetooth | No |
Input
| Input voltage range | 9 to 18 V |
| Under-voltage shutdown | 8 V |
| Under-voltage restart | 10 V |
| Off load current | < 10 mA |
Output
| Output voltage | 24 V (fixed) |
| Adjustable output | No |
| Continuous output current | 8 A |
| Maximum output current | 20 A |
| Maximum efficiency | 95 % |
| Suitable to buffer-charge a battery | No |
General
| Galvanic isolation | No |
| Fan assisted cooling | No |
| Remote on/off | No |
| Parallel operation | No |
Environmental
| Operating temperature range | -20 to +55 degrees C (derate 3 % per degree C above 40) |
Physical
| DC connection | Faston tabs 6.3 mm |
| Weight | 0.4 kg |
| Dimensions (h x w x d) | 45 x 90 x 115 mm |
Conformance
| Safety | EN 60950 |
| Emission | EN 61000-6-3, EN 55014-1 |
| Immunity | EN 61000-6-2, EN 61000-6-1, EN 55014-2 |
