Victron Orion 24/12-30 Non-Isolated DC-DC Converter
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Orion 24/12-30 is a non-isolated DC-DC converter that steps a 24V supply down to a 12V output, delivering up to 30A (360W continuous). The output is adjustable with a potentiometer over a 10 to 15V range, with a factory setting of 13.2V, so it can power 12V equipment from a 24V system or buffer-charge a 12V battery from a 24V source.
This latest-generation model is highly efficient at around 96 percent and holds a stable output across an 18 to 35V input. A remote on/off connector removes the need for a high-current switch in the input wiring and can be operated by a low-power switch or the engine run/stop signal. Adjustable-output models can be paralleled, up to five units, to increase the available output current.
Connections are made with 6.3 mm Faston tabs and the supply includes insulated female crimp terminals, so the unit installs quickly without special tools.
PRODUCT DETAILS
- 24V to 12V non-isolated conversion at up to 30A (360W continuous)
- Output adjustable 10 to 15V with potentiometer, factory set to 13.2V
- Can power 12V equipment or buffer-charge a 12V battery from a 24V source
- High efficiency of around 96 percent
- Remote on/off connector for low-power or engine run/stop switching
- Wide 18 to 35V input range
- Up to five units can be paralleled to increase output
- 6.3 mm Faston tab connections, crimp terminals supplied
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Input voltage range | 18 to 35 V |
| Output voltage (nominal) | 12 V (adjustable 10 to 15 V, set 13.2 V) |
| Continuous output current | 30 A |
| Continuous output power | 360 W (12 V x 30 A) |
| Galvanic isolation | Non-isolated |
| Bluetooth | No |
Input
| Input voltage range | 18 to 35 V |
| Under-voltage shutdown | 14 V |
| Under-voltage restart | 18 V |
| Off load current | < 15 mA |
Output
| Output voltage (factory set) | 13.2 V |
| Output voltage adjustment range | 10 to 15 V (potentiometer) |
| Continuous output current | 30 A |
| Maximum output current | 40 A |
| Maximum efficiency | 96 % |
| Suitable to buffer-charge a battery | Yes |
General
| Galvanic isolation | No |
| Fan assisted cooling | No |
| Remote on/off | Yes |
| Parallel operation | Yes, up to five units |
Environmental
| Operating temperature range | -20 to +55 degrees C (derate 3 % per degree C above 40) |
Physical
| DC connection | Faston tabs 6.3 mm |
| Weight | 0.7 kg |
| Dimensions (h x w x d) | 65 x 88 x 160 mm |
Conformance
| Safety | EN 60950 |
| Emission | EN 61000-6-3, EN 55014-1 |
| Immunity | EN 61000-6-2, EN 61000-6-1, EN 55014-2 |
