Victron Orion 12/24-10 Non-Isolated DC-DC Converter
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Orion 12/24-10 is a non-isolated DC-DC converter that steps a 12V supply up to a 24V output, delivering up to 10A (240W continuous). The output is adjustable with a potentiometer over a 20 to 30V range, with a factory setting of 26.4V, so it can power 24V equipment from a 12V system or buffer-charge a 24V battery from a 12V source.
Efficiency is around 95 percent and the converter holds a stable output across a 9 to 18V input. It is fanless and draws a low off-load current. Adjustable-output models in this range can also be connected in parallel, up to five units, to increase the available output current.
Connections are made with 6.3 mm Faston tabs and the supply includes insulated female crimp terminals, allowing quick installation without special tools.
PRODUCT DETAILS
- 12V to 24V non-isolated conversion at up to 10A (240W continuous)
- Output adjustable 20 to 30V with potentiometer, factory set to 26.4V
- Can power 24V equipment or buffer-charge a 24V battery from a 12V source
- Efficiency of around 95 percent
- Wide 9 to 18V input range, fanless design
- Up to five units can be paralleled to increase output
- 6.3 mm Faston tab connections, crimp terminals supplied
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Input voltage range | 9 to 18 V |
| Output voltage (nominal) | 24 V (adjustable 20 to 30 V, set 26.4 V) |
| Continuous output current | 10 A |
| Continuous output power | 240 W (24 V x 10 A) |
| Galvanic isolation | Non-isolated |
| Bluetooth | No |
Input
| Input voltage range | 9 to 18 V |
| Under-voltage shutdown | 8 V |
| Under-voltage restart | 10 V |
| Off load current | < 15 mA |
Output
| Output voltage (factory set) | 26.4 V |
| Output voltage adjustment range | 20 to 30 V (potentiometer) |
| Continuous output current | 10 A |
| Maximum output current | 20 A |
| Maximum efficiency | 95 % |
| Suitable to buffer-charge a battery | Yes |
General
| Galvanic isolation | No |
| Fan assisted cooling | No |
| Remote on/off | No |
| Parallel operation | Yes, up to five units |
Environmental
| Operating temperature range | -20 to +55 degrees C (derate 3 % per degree C above 40) |
Physical
| DC connection | Faston tabs 6.3 mm |
| Weight | 0.4 kg |
| Dimensions (h x w x d) | 45 x 90 x 125 mm |
Conformance
| Safety | EN 60950 |
| Emission | EN 61000-6-3, EN 55014-1 |
| Immunity | EN 61000-6-2, EN 61000-6-1, EN 55014-2 |
