Victron Phoenix Inverter 12/375 VE.Direct (IEC)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Phoenix Inverter 12/375 VE.Direct converts 12V battery power into a clean 230V AC supply, letting you run mains equipment from a leisure or starter battery aboard a boat, in a campervan or at an off-grid site. The full bridge and toroidal transformer design has proven its reliability over many years and is fully short circuit proof, with protection against overheating from overload or high ambient temperature.
Its pure sine wave output is identical in quality to grid power, so it drives sensitive electronics such as laptops, chargers and audio visual gear without interference. A generous 700W of peak power handles the brief surge that motors, pumps and electronic transformers draw at switch on, making it well suited to laptops, chargers, LED lighting, a small fridge or modest power tools.
The built in VE.Direct port connects to a phone, tablet or computer through an optional VE.Direct to USB cable or Bluetooth Smart dongle, giving live readings of input and output voltage, load and alarms. ECO mode drops the inverter to a low power standby when the load falls away, which conserves the battery during long unattended periods. This unit is fitted with an IEC-320 outlet and ships with a male plug for easy connection.
PRODUCT DETAILS
- Pure sine wave 230V output, identical in quality to mains power for sensitive electronics
- 375VA continuous (300W at 25C) with 700W peak to cover start up surges
- 12V DC input with adjustable low voltage shut down to protect the battery
- VE.Direct port for live monitoring and full configuration via USB cable or Bluetooth dongle
- ECO mode drops the unit to low power standby when the load is small
- Short circuit, overload and over temperature protection with audible and visual battery alarm
- IEC-320 output socket with a male plug included
- Compact steel chassis, fan assisted cooling and a 5 year warranty
No compatible transducers listed for this product.
Key specifications
| Continuous power (VA) | 375 VA |
| Continuous power (W) | 300 W at 25C |
| Peak power | 700 W |
| System voltage | 12 V |
| Output voltage & frequency | 230 VAC, 50 Hz |
| Maximum efficiency | 89% |
Output
| Continuous power at 40°C | 260 W |
| Output AC voltage (adjustable) | 210 - 245 V |
| Output frequency (adjustable) | 50 Hz or 60 Hz, +/-0.1% |
| Output waveform | Pure sine wave |
Input
| Input voltage range | 9.2 - 17 V |
| DC low-voltage shut-down (adjustable) | 9.3 V |
| Dynamic (load-dependent) DC low shut-down | Load dependent cut-off, fully configurable |
| DC low-voltage restart & alarm (adjustable) | 10.9 V |
| Battery charged detect (adjustable) | 14.0 V |
General
| Zero-load power | 5.6 W |
| Zero-load power in ECO mode | 0.9 W |
| ECO mode stop and start power setting | Adjustable |
| ECO mode minimum load | 15 W |
| Protections | Output short circuit, overload, battery voltage too high, battery voltage too low, temperature too high, DC ripple too high |
| Communication port | VE.Direct (USB or Bluetooth dongle sold separately) |
| Remote on/off | Yes (two-pole connector) |
Environmental
| Operating temperature range | -40 to +65C (derate 1.25% per C above 40C) |
| Cooling | Fan-assisted |
| Humidity (non-condensing) | Max 95% |
Enclosure
| Material & colour | Steel chassis, plastic cover, blue RAL 5012 |
| Battery connection | Screw terminals |
| Maximum cable cross-section | 10 mm2 (AWG8) |
| Standard AC outlet socket | IEC-320 (male plug included) |
| Protection category | IP21 |
| Dimensions (H x W x D) | 86 x 165 x 260 mm |
| Weight | 3.0 kg |
Standards & Certifications
| Safety | EN-IEC 60335-1, EN-IEC 62109-1 |
| EMC | EN 55014-1, EN 55014-2, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 |
| Automotive Directive | ECE R10-4 |
