Victron
Victron Phoenix Inverter 12/500 with DEFA 1m Cable
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Phoenix Inverter 12/500 turns 12V battery power into clean 230V mains electricity, letting you run mains appliances and tools from your boat or vehicle batteries. It delivers a true pure sine wave output, so sensitive electronics, chargers and motors run quietly and reliably, just as they would at home.
This Hudson Marine package supplies the inverter ready-fitted with a one-metre DEFA extension cable, so it drops straight into a DEFA based shore-power or interior-heater installation without extra wiring. The compact steel-cased unit offers a continuous 400W (500VA), a 900W surge for start-up loads, and a frugal ECO mode that cuts standby draw when nothing is connected. A two-pole remote on/off input and a VE.Direct data port make it easy to integrate and monitor.
PRODUCT DETAILS
- Pure sine wave 230V output for clean, reliable power to sensitive electronics
- Supplied with a DEFA one-metre extension cable pre-connected
- 400W continuous (500VA) with a 900W peak for start-up surges
- ECO mode cuts standby consumption when no load is present
- Remote on/off input and VE.Direct port for monitoring and control
- Rugged steel chassis with fan-assisted cooling and full electronic protection
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Continuous power (VA) | 500 VA |
| Continuous power (W) | 400 W |
| Peak power | 900 W |
| System voltage | 12 V |
| Output voltage & frequency | 230 VAC, 50 Hz |
| Maximum efficiency | 90% |
Output
| Continuous power at 40°C | 350 W |
| Output AC voltage (adjustable) | 210 - 245 V |
| Output frequency (adjustable) | 50 Hz or 60 Hz ±0.1% |
| Output waveform | Pure sine wave |
Input
| Input voltage range | 9.2 - 17 V |
| DC low-voltage shut-down (adjustable) | 9.3 V |
| DC low-voltage restart & alarm (adjustable) | 10.9 V |
| Battery charged detect (adjustable) | 14.0 V |
General
| Zero-load power | 6 W |
| Zero-load power in ECO mode | 1 W |
| ECO mode stop and start power setting | Adjustable |
| ECO mode minimum load | 15 W |
| Protections | Output short circuit, overload, battery voltage too high, battery voltage too low, temperature too high, DC ripple too high |
| Communication port | VE.Direct (USB or Bluetooth dongle sold separately) |
| Remote on/off | Yes (two-pole connector) |
Environmental
| Operating temperature range | -40 to +65°C (derate 1.25% per °C above 40°C) |
| Cooling | Fan-assisted |
| Humidity (non-condensing) | Max 95% |
Enclosure
| Material & colour | Steel chassis, plastic cover, blue RAL 5012 |
| Battery connection | Screw terminals |
| Maximum cable cross-section | 10 mm² (AWG8) |
| Standard AC outlet socket | Schuko CEE 7/4 |
| Protection category | IP21 |
| Dimensions (H x W x D) | 86 x 165 x 260 mm |
| Weight | 3.9 kg |
Standards & Certifications
| Safety | EN-IEC 60335-1, EN-IEC 62109-1 |
| EMC | EN 55014-1, EN 55014-2, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 |
| Automotive Directive | ECE R10-4 |
