Victron
Victron Phoenix Inverter 24/500 VE.Direct (Schuko)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Phoenix Inverter 24/500 VE.Direct turns 24V battery power into a clean 230V AC supply, giving you mains-quality electricity wherever you are. Its pure sine wave output drives sensitive electronics, chargers and small appliances exactly as they expect, making it ideal for boats, campervans and off-grid cabins where a reliable, compact inverter matters.
Built around Victron's proven full-bridge and toroidal transformer design, the unit is short-circuit proof and protected against overheating from overload or high ambient temperatures. A high start-up power reserve handles demanding loads such as LED drivers and power tools, while the fan-assisted housing keeps everything cool under continuous use.
The integrated VE.Direct port lets you monitor and configure the inverter from a phone, tablet or computer using a VE.Direct to USB cable or a VE.Direct Bluetooth Smart dongle. ECO mode drops the inverter into low-consumption standby when no load is present, and a remote on/off connection lets you switch it from the helm or living space.
PRODUCT DETAILS
- Pure sine wave output for safe operation of sensitive electronics and appliances
- 500VA continuous power with a 900W peak for demanding start-up loads
- Schuko CEE 7/4 output socket
- VE.Direct port for monitoring and configuration via VictronConnect
- ECO mode reduces standby consumption when no load is connected
- Short-circuit, overload and over-temperature protection built in
- Remote on/off via a two-pole connector for convenient control
- Five-year warranty from Victron Energy
No compatible transducers listed for this product.
Key specifications
| Continuous power (VA) | 500 VA |
| Continuous power (W) | 400 W |
| Peak power | 900 W |
| System voltage | 24 V |
| Output voltage & frequency | 230 VAC, 50 Hz |
| Maximum efficiency | 90% |
Output
| Continuous power at 40°C | 350 W |
| Output AC voltage (adjustable) | 210 - 245 V |
| Output frequency (adjustable) | 50 Hz or 60 Hz ±0.1% |
| Output waveform | Pure sine wave |
Input
| Input voltage range | 18.4 - 34.0 V |
| DC low-voltage shut-down (adjustable) | 18.6 V |
| Dynamic (load-dependent) DC low shut-down | Fully configurable |
| DC low-voltage restart & alarm (adjustable) | 21.8 V |
| Battery charged detect (adjustable) | 28.0 V |
General
| Zero-load power | 6.5 W |
| Zero-load power in ECO mode | 1.5 W |
| ECO mode stop and start power setting | Adjustable |
| ECO mode minimum load | 15 W |
| Protections | Output short circuit, overload, battery voltage too high, battery voltage too low, temperature too high, DC ripple too high |
| Communication port | VE.Direct (USB or Bluetooth dongle sold separately) |
| Remote on/off | Yes (two-pole connector) |
Environmental
| Operating temperature range | -40 to +65°C (derate 1.25% per °C above 40°C) |
| Cooling | Fan-assisted |
| Humidity (non-condensing) | Max 95% |
Enclosure
| Material & colour | Steel chassis, plastic cover, blue RAL 5012 |
| Battery connection | Screw terminals |
| Maximum cable cross-section | 10 mm² (AWG8) |
| Standard AC outlet socket | Schuko CEE 7/4 |
| Protection category | IP21 |
| Dimensions (H x W x D) | 86 x 165 x 260 mm |
| Weight | 3.9 kg |
Standards & Certifications
| Safety | EN-IEC 60335-1, EN-IEC 62109-1 |
| EMC | EN 55014-1, EN 55014-2, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 |
| Automotive Directive | ECE R10-4 |
