Victron Phoenix Inverter 48/1200 VE.Direct (IEC)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Phoenix Inverter 48/1200 VE.Direct converts 48V battery power into a clean 230V pure sine wave AC supply, ideal for running sensitive electronics aboard a boat or in an off-grid installation. Built around a proven full-bridge and toroidal transformer topology, it delivers dependable power with the low standby draw that makes it well suited to long unattended use.
An integrated VE.Direct port lets you monitor and configure the inverter from a phone, tablet or computer using a VE.Direct to USB cable or a Bluetooth Smart dongle (sold separately). ECO mode drops the unit into standby when no significant load is present, cutting idle consumption to conserve the battery bank. As the largest model in the VE.Direct range it offers 2200 W of peak power for demanding start-up loads, a two-pole remote on/off connector and fan-assisted cooling.
PRODUCT DETAILS
- Pure sine wave output for safe operation of sensitive electronics
- 1200 VA continuous power with 2200 W peak for high start-up loads
- VE.Direct communication port for monitoring and full configuration
- ECO mode reduces standby consumption to conserve the battery
- Remote on/off via two-pole connector
- High efficiency up to 92% with low zero-load power draw
- Fan-assisted cooling with comprehensive overload and short-circuit protection
- Robust steel chassis with IEC-320 outlet socket (male plug included)
No compatible transducers listed for this product.
Key specifications
| Continuous power (VA) | 1200 VA |
| Continuous power (W) | 1000 W at 25°C |
| Peak power | 2200 W |
| System voltage | 48 V |
| Output voltage & frequency | 230 VAC, 50 Hz |
| Maximum efficiency | 92% |
Output
| Continuous power at 40°C | 850 W |
| Output AC voltage (adjustable) | 210 - 245 V |
| Output frequency (adjustable) | 50 Hz or 60 Hz ±0.1% |
| Output waveform | Pure sine wave |
Input
| Input voltage range | 36.8 - 62.0 V |
| DC low-voltage shut-down (adjustable) | 37.2 V |
| Dynamic (load-dependent) DC low shut-down | Fully configurable |
| DC low-voltage restart & alarm (adjustable) | 43.6 V |
| Battery charged detect (adjustable) | 56.0 V |
General
| Zero-load power | 12 W |
| Zero-load power in ECO mode | 3.0 W |
| ECO mode stop and start power setting | Adjustable |
| ECO mode minimum load | 15 W |
| Protections | Output short circuit, overload, battery voltage too high, battery voltage too low, temperature too high, DC ripple too high |
| Communication port | VE.Direct (USB or Bluetooth dongle sold separately) |
| Remote on/off | Yes (two-pole connector) |
Environmental
| Operating temperature range | -40 to +65°C (derate 1.25% per °C above 40°C) |
| Cooling | Fan-assisted |
| Humidity (non-condensing) | Max 95% |
Enclosure
| Material & colour | Steel chassis, plastic cover, blue RAL 5012 |
| Battery connection | Screw terminals |
| Maximum cable cross-section | 25 mm² (AWG4) |
| Standard AC outlet socket | IEC-320 (male plug included) |
| Protection category | IP21 |
| Dimensions (H x W x D) | 105 x 216 x 305 mm |
| Weight | 7.4 kg |
Standards & Certifications
| Safety | EN-IEC 60335-1, EN-IEC 62109-1 |
| EMC | EN 55014-1, EN 55014-2, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 |
| Automotive Directive | ECE R10-4 |
