Victron Phoenix Inverter Smart 12/3000
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Phoenix Inverter Smart 12/3000 turns 12V battery power into a clean 230V AC supply, ready to run the everyday mains appliances on a boat, motorhome or off-grid installation. Built on Victron's proven full-bridge and toroidal-transformer platform, it delivers a stable, high-quality pure sine wave with the surge capacity needed to start demanding loads such as power tools, pumps and LED or halogen lighting.
Bluetooth is built in, so the whole inverter can be configured and monitored from a phone or tablet using the free VictronConnect app. Output voltage, frequency, ECO mode, low-voltage cut-off and the programmable alarm relay are all adjustable, and a VE.Direct port allows wired connection to a GX device for full system integration.
A slim full-metal casing and accessible terminals make for a tidy, professional installation, while ECO mode keeps standby consumption low when no load is present. Like all Victron inverters it is short-circuit proof and protected against overload and overheating, and is backed by a 5-year warranty.
PRODUCT DETAILS
- 3000VA continuous output from a 12V battery bank with 6000W peak surge power
- Pure sine wave output for safe, quiet running of sensitive electronics
- Built-in Bluetooth for wireless setup and monitoring via VictronConnect
- VE.Direct communication port for wired GX system integration
- ECO mode reduces standby power consumption when no load is connected
- Programmable alarm relay plus remote on/off control
- Short-circuit, overload and over-temperature protection
- Slim full-metal casing with accessible terminals for a professional install
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Continuous power (VA) | 3000 VA |
| Continuous power (W) | 2400 W at 25°C |
| Peak power | 6000 W |
| System voltage | 12 V |
| Output voltage & frequency | 230 VAC, 50 Hz |
| Maximum efficiency | 93% |
Output
| Continuous power at 40°C | 2200 W |
| Continuous power at 65°C | 1700 W |
| Output AC voltage (adjustable) | 210 - 245 V |
| Output frequency (adjustable) | 50 Hz or 60 Hz ±0.1% |
| Output waveform | Pure sine wave |
Input
| Input voltage range | 9.3 - 17 V |
| Dynamic (load-dependent) DC low shut-down | Dynamic cut-off, fully configurable |
General
| Zero-load power | 12 W |
| Zero-load power in ECO mode | 1.5 W |
| ECO mode stop and start power setting | Adjustable |
| Protections | Output short circuit, overload, battery voltage too high, battery voltage too low, temperature too high, 230 VAC on inverter output, input voltage ripple too high |
| Communication port | VE.Direct and Bluetooth |
| Programmable relay | Yes (AC 230 V / 4 A, DC 4 A / 35 VDC) |
| Remote on/off | Yes |
Environmental
| Operating temperature range | -40 to +65°C |
| Cooling | Fan-assisted |
| Humidity (non-condensing) | Max 95% |
Enclosure
| Material & colour | Steel, blue RAL 5012 |
| Battery connection | 2 + 2 M8 bolts |
| AC connection | Screw terminals |
| Protection category | IP21 |
| Dimensions (H x W x D) | 533 x 285 x 150 mm |
| Weight | 19 kg |
Standards & Certifications
| Safety | EN 60335-1 |
| EMC | EN 55014-1, EN 55014-2, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3 |
| Automotive Directive | ECE R10-5 |
