Victron Skylla-TG 24/50 Battery Charger - 230 VAC
£766.80
/
Tax included.
SDTG2400501
The Victron Skylla-TG 24/50 is a 24 V, 50 A marine battery charger with a 230 VAC input. It offers two isolated outputs, IUoUo three-step charging and temperature-compensated voltage control for reliable house and starter battery charging.
✓
Available for collection or delivery in ~2 days
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Skylla-TG 24/50 is a robust, microprocessor-controlled 24 V marine battery charger that delivers up to 50 A from a 230 VAC supply. It can also be used as a stabilised DC power supply where a regulated 24 V output is required.
Charging follows the IUoUo three-step characteristic, with a supplied battery temperature sensor and battery voltage sense ensuring an accurate charge in all conditions. A second 4 A output is provided to keep a starter battery topped up alongside the main house bank.
Built into a sea-water-resistant aluminium enclosure with forced-air cooling and an IP21 rating, the charger is designed for the marine environment and can stay connected to the batteries during storage.
PRODUCT DETAILS
- 24 V charging at up to 50 A from a 230 VAC supply
- Two isolated outputs: full-current house output plus a 4 A starter-battery output
- IUoUo three-step charge characteristic with selectable 4, 8 or 12 hour absorption
- Supplied battery temperature sensor for temperature-compensated charging
- Battery voltage sense to compensate for cable voltage loss up to 2 V
- Can be used as a stabilised DC power supply
- Sea-water-resistant aluminium case, force-cooled, IP21 rated
- Potential-free alarm contact and remote on/off capability
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Battery voltage | 24 V |
| Charge current | 50 A |
| Number of outputs | 1+1 |
| Maximum efficiency | 85 % |
Charging
| Charge algorithm | IUoUo (three step: bulk, absorption, float) |
| Charge current starter battery | 4 A |
| Charge voltage 'absorption' | 28.5 V |
| Charge voltage 'float' | 26.5 V |
| Recommended battery capacity | 250 - 500 Ah |
| Temperature compensation | External battery temperature sensor (supplied) |
Input
| AC input voltage range | 185 - 264 VAC (230 V nominal) |
| DC input voltage range | 180 - 400 V |
| Input frequency | 45 - 65 Hz |
| Maximum input current setting | 8 A at 30 V (full output) |
| Power factor | 1 |
Connectivity & control
| Battery temperature sensor | Yes, external sensor supplied |
| Programmable relay | Potential-free alarm contact 60 V / 1 A (1x NO and 1x NC) |
| Battery voltage sense | Yes, compensates up to 2 V cable loss |
| Remote on/off | Yes, via remote panel or switch |
Protection
| Protection | Output short circuit, battery reverse polarity detection, battery voltage too high, temperature too high |
Environmental
| Operating temperature | -40 to +50°C (full output up to 40°C) |
| Cooling | Forced air cooling |
| Humidity | Max 95% (non-condensing) |
Physical
| Colour | Blue (RAL 5012) |
| Material | Aluminium, sea-water resistant, epoxy powder coated |
| Protection category | IP21 |
| Terminals | M8 studs (battery), screw-clamp 2.5 mm² / AWG 6 (AC) |
| Weight | 12.8 kg |
| Dimensions (h x w x d) | 368 x 250 x 257 mm |
Conformance
| Safety | EN 60335-1, EN 60335-2-29 |
| Emission / Immunity | EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3 |
No videos available for this product.
How many batteries can the Skylla-TG 24/50 charge at once?
The Skylla-TG 24/50 has two isolated outputs, so it can charge two battery banks at the same time. The main output delivers the full charge current to the house bank, while a separate output provides up to 4 A to top up a starter battery.
What charge profile does the Skylla-TG 24/50 use?
It uses the IUoUo three-step charge characteristic, charging in bulk, absorption and float stages with an absorption voltage of 28.5 V and a float voltage of 26.5 V. The absorption time can be set to 4, 8 or 12 hours to suit your batteries.
Can the charger stay connected to the batteries permanently?
Yes. The charger can remain connected to the batteries at all times, making it well suited to keeping a vessel topped up during storage. The float stage maintains the batteries without overcharging them.
How does the charger compensate for temperature and cable losses?
A battery temperature sensor is supplied as standard, allowing the charge voltage to be adjusted for battery temperature. Battery voltage sense further compensates for voltage loss in the cabling of up to 2 V, so the batteries receive the correct charge voltage.
Can the Skylla-TG 24/50 be used as a DC power supply?
Yes. As well as charging batteries, the Skylla-TG 24/50 can be used as a stabilised DC power supply, providing a regulated 24 V output for connected equipment.
