Victron Skylla-TG 24/50 Battery Charger - 3-Phase
£1,393.20
/
Tax included.
STG024050300
The Victron Skylla-TG 24/50 3-Phase is a 24 V, 50 A marine battery charger fed from a 3 x 400 V three-phase supply. It offers two isolated outputs with IUoUo three-step charging and temperature-compensated voltage control.
✓
Collection or delivery in 1-2 weeks
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Skylla-TG 24/50 3-Phase is a 24 V, 50 A marine battery charger powered from a 3 x 400 V three-phase mains (320 to 450 VAC). It is suited to larger vessels and commercial installations where three-phase shore or generator power is available, with the three-phase input taken through a magnetic circuit breaker.
Charging follows the IUoUo three-step characteristic, with a supplied battery temperature sensor and battery voltage sense ensuring an accurate charge. A 4 A second output tops up a starter battery alongside the main house bank.
Built into a sea-water-resistant aluminium enclosure with forced-air cooling and an IP21 rating, the charger can stay connected to the batteries during storage. Note that, unlike the single-phase Skylla-TG models, the 3-phase version does not accept a DC supply.
PRODUCT DETAILS
- 24 V charging at up to 50 A from a 3 x 400 V three-phase supply
- Three-phase input via integral magnetic circuit breaker
- Two isolated outputs: full-current house output plus a 4 A starter-battery output
- IUoUo three-step charge characteristic with selectable 4, 8 or 12 hour absorption
- Supplied battery temperature sensor for temperature-compensated charging
- Battery voltage sense to compensate for cable voltage loss up to 2 V
- Can be used as a stabilised DC power supply
- Sea-water-resistant aluminium case, force-cooled, IP21 rated
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Battery voltage | 24 V |
| Charge current | 50 A |
| Number of outputs | 1+1 |
| Maximum efficiency | 85 % |
Charging
| Charge algorithm | IUoUo (three step: bulk, absorption, float) |
| Charge current starter battery | 4 A |
| Charge voltage 'absorption' | 28.5 V |
| Charge voltage 'float' | 26.5 V |
| Recommended battery capacity | 400 - 800 Ah |
| Temperature compensation | External battery temperature sensor (supplied) |
Input
| AC input voltage range | 320 - 450 VAC (3-phase, 3 x 400 V nominal) |
| DC input voltage range | Not applicable (3-phase AC input only) |
| Input frequency | 45 - 65 Hz |
| Maximum input current setting | 3 x 3 A at 30 V (full output) |
| Power factor | 1 |
Connectivity & control
| Battery temperature sensor | Yes, external sensor supplied |
| Programmable relay | Potential-free alarm contact 60 V / 1 A (1x NO and 1x NC) |
| Battery voltage sense | Yes, compensates up to 2 V cable loss |
| Remote on/off | Yes, via remote panel or switch |
Protection
| Protection | Output short circuit, battery reverse polarity detection, battery voltage too high, temperature too high |
Environmental
| Operating temperature | -40 to +50°C (full output up to 40°C) |
| Cooling | Forced air cooling |
| Humidity | Max 95% (non-condensing) |
Physical
| Colour | Blue (RAL 5012) |
| Material | Aluminium, sea-water resistant, epoxy powder coated |
| Protection category | IP21 |
| Terminals | M8 studs (battery); 3-phase input via magnetic circuit breaker |
| Weight | 10 kg |
| Dimensions (h x w x d) | 515 x 260 x 265 mm |
Conformance
| Safety | EN 60335-1, EN 60335-2-29 |
| Emission / Immunity | EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3 |
No videos available for this product.
What supply does the Skylla-TG 24/50 3-Phase need?
This model is fed from a 3 x 400 V three-phase supply, accepting an input range of 320 to 450 VAC, with the three-phase input taken through a magnetic circuit breaker. Unlike the single-phase Skylla-TG models, the 3-phase version does not accept a DC supply.
How many batteries can the 3-Phase charger charge at once?
The charger has two isolated outputs, so it can charge two banks at the same time. The main output supplies the full charge current to the house bank, while a separate output delivers up to 4 A to top up a starter battery.
What charge profile does the 3-Phase model use?
It uses the IUoUo three-step charge characteristic, working through bulk, absorption and float stages with an absorption voltage of 28.5 V and a float voltage of 26.5 V. The absorption time can be set to 4, 8 or 12 hours to suit your batteries.
How does the charger compensate for temperature and cable losses?
A battery temperature sensor is supplied as standard, allowing the charge voltage to be adjusted for battery temperature. Battery voltage sense further compensates for cable voltage loss of up to 2 V, so the batteries receive the correct charge voltage.
What battery capacity is recommended for the 3-Phase 24/50?
Victron recommends a battery capacity of 400 to 800 Ah for the Skylla-TG 24/50 3-Phase. This larger range reflects its use on bigger vessels and commercial installations with three-phase power.
