Victron Skylla-TG 24/50 GMDSS Battery Charger
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
GMDSS (Global Maritime Distress and Safety System) was developed by the IMO to improve maritime distress and safety communications. The Skylla-TG GMDSS charger is designed to provide all the required monitoring and alarm data, with the battery and the GMDSS system connected directly to the charger. A built-in battery controller fully monitors capacity so the optional VE.Net GMDSS panel can show battery time-to-go in the event of a power blackout.
It charges 24 V batteries at up to 50 A from a 90-265 VAC supply using the IUoUo three-step characteristic, with temperature-compensated charging. The system is pre-programmed and ''click and go'', and connects to the panel with a standard eight-wire UTP cable.
Built in a sea-water-resistant aluminium enclosure finished in Victron blue, force-cooled and rated IP21, it also complies with IEC 60945 for maritime navigation and radiocommunication equipment.
PRODUCT DETAILS
- Purpose-built charger and power supply for GMDSS installations
- 24 V charging at up to 50 A from a 90-265 VAC supply
- Built-in battery controller with battery time-to-go indication
- Pre-programmed click-and-go operation with optional VE.Net GMDSS panel
- IUoUo three-step charging with temperature compensation
- Complies with IEC 60945 for maritime equipment
- Sea-water-resistant aluminium case, force-cooled, IP21 rated
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Battery voltage | 24 V |
| Charge current | 50 A |
| Number of outputs | 1+1 |
Charging
| Charge algorithm | IUoUo (three step: bulk, absorption, float) |
| Charge voltage 'absorption' | 28.5 V |
| Charge voltage 'float' | 26.5 V |
| Temperature compensation | External battery temperature sensor |
Input
| AC input voltage range | 90 - 265 VAC (120/230 V nominal) |
| Input frequency | 45 - 65 Hz |
| Power factor | 1 |
Connectivity & control
| Battery temperature sensor | Yes |
| Battery monitoring | Built-in battery controller with battery time-to-go indication (VE.Net GMDSS panel, ordered separately) |
Protection
| Protection | Output short circuit, battery reverse polarity detection, battery voltage too high, temperature too high |
Environmental
| Operating temperature | -40 to +50°C |
| Cooling | Forced air cooling |
| Humidity | Max 95% (non-condensing) |
Physical
| Colour | Blue (RAL 5012) |
| Material | Aluminium (blue RAL 5012) |
| Protection category | IP21 |
| Terminals | Two 1.5 m battery cables; one 1.5 m GMDSS cable; 2 m three-wire 2.5 mm² (AWG 6) AC cable |
| Weight | 6 kg |
| Dimensions (h x w x d) | 485 x 250 x 147 mm |
Conformance
| Safety | EN 60335-1, EN 60335-2-29 |
| Emission / Immunity | EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3 |
| Maritime navigation & radiocommunication | IEC 60945 |
