Victron Skylla-TG 48/25 Battery Charger - 230 VAC
£921.60
/
Tax included.
SDTG4800251
The Victron Skylla-TG 48/25 is a 48 V, 25 A marine battery charger with a 230 VAC input. It uses IUoUo three-step charging with temperature compensation and a stabilised output for reliable charging of 48 V banks.
✓
Available for collection or delivery in ~2 days
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Skylla-TG 48/25 is a robust, microprocessor-controlled 48 V marine battery charger that delivers up to 25 A from a 230 VAC supply. It can also serve as a stabilised DC power supply where a regulated 48 V output is needed.
Charging follows the IUoUo three-step characteristic, with a supplied battery temperature sensor and battery voltage sense ensuring an accurate charge in all conditions. The absorption time can be set to suit the battery bank.
Built into a sea-water-resistant aluminium enclosure with forced-air cooling and an IP21 rating, the charger is designed for the marine environment and can stay connected to the batteries during storage.
PRODUCT DETAILS
- 48 V charging at up to 25 A from a 230 VAC supply
- IUoUo three-step charge characteristic with selectable 4, 8 or 12 hour absorption
- Supplied battery temperature sensor for temperature-compensated charging
- Battery voltage sense to compensate for cable voltage loss up to 2 V
- Can be used as a stabilised DC power supply
- Sea-water-resistant aluminium case, force-cooled, IP21 rated
- Potential-free alarm contact and remote on/off capability
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Key specifications
| Battery voltage | 48 V |
| Charge current | 25 A |
| Number of outputs | 1 |
| Maximum efficiency | 85 % |
Charging
| Charge algorithm | IUoUo (three step: bulk, absorption, float) |
| Charge voltage 'absorption' | 57 V |
| Charge voltage 'float' | 53 V |
| Recommended battery capacity | 125 - 250 Ah |
| Temperature compensation | External battery temperature sensor (supplied) |
Input
| AC input voltage range | 185 - 264 VAC (230 V nominal) |
| DC input voltage range | 180 - 400 V |
| Input frequency | 45 - 65 Hz |
| Maximum input current setting | 8 A at 60 V (full output) |
| Power factor | 1 |
Connectivity & control
| Battery temperature sensor | Yes, external sensor supplied |
| Programmable relay | Potential-free alarm contact 60 V / 1 A (1x NO and 1x NC) |
| Battery voltage sense | Yes, compensates up to 2 V cable loss |
| Remote on/off | Yes, via remote panel or switch |
Protection
| Protection | Output short circuit, battery reverse polarity detection, battery voltage too high, temperature too high |
Environmental
| Operating temperature | -40 to +50°C (full output up to 40°C) |
| Cooling | Forced air cooling |
| Humidity | Max 95% (non-condensing) |
Physical
| Colour | Blue (RAL 5012) |
| Material | Aluminium, sea-water resistant, epoxy powder coated |
| Protection category | IP21 |
| Terminals | M8 studs (battery), screw-clamp 2.5 mm² / AWG 6 (AC) |
| Weight | 5.5 kg |
| Dimensions (h x w x d) | 365 x 250 x 147 mm |
Conformance
| Safety | EN 60335-1, EN 60335-2-29 |
| Emission / Immunity | EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3 |
No videos available for this product.
What battery voltage and charge profile does the 48/25 use?
The Skylla-TG 48/25 charges 48 V battery banks using the IUoUo three-step characteristic, working through bulk, absorption and float stages. The absorption voltage is 57 V and the float voltage is 53 V, with the absorption time selectable at 4, 8 or 12 hours.
Can the charger stay connected to the batteries permanently?
Yes. The charger can remain connected to the batteries at all times, which makes it ideal for keeping a 48 V bank topped up during storage. The float stage maintains the batteries without overcharging them.
How does the charger compensate for temperature and cable losses?
A battery temperature sensor is supplied as standard so the charge voltage can be adjusted for battery temperature. Battery voltage sense additionally compensates for cable voltage loss of up to 2 V, ensuring the batteries receive the correct charge voltage.
Can the Skylla-TG 48/25 be used as a DC power supply?
Yes. In addition to charging batteries, the Skylla-TG 48/25 can be used as a stabilised DC power supply, delivering a regulated 48 V output for connected equipment.
What battery capacity is recommended for the 48/25?
Victron recommends a battery capacity of 125 to 250 Ah for the Skylla-TG 48/25. This range ensures the 25 A charge current is well matched to the size of the battery bank.
