Fusion Apollo Monoblock Marine Amplifier (650-watt RMS)
Description
The Fusion Apollo monoblock amplifier is engineered to produce impressive, efficient power with less drain on your boat battery. This single-channel Class-D amplifier delivers 650 W RMS at 4 ohms and up to 1100 W RMS at 2 ohms, dedicating all of its output to driving one or more marine subwoofers for deep, controlled low-end.
Designed to integrate with your compatible Fusion stereo system, the Apollo amplifier is quick to install and features a self-resetting electronic fuse, so there is no fuse to replace. A rugged, corrosion-resistant chassis and ignition-protected design make it well suited to the demands of the marine environment.
PRODUCT DETAILS
- Class-D monoblock delivering 650 W RMS at 4 ohms and up to 1100 W RMS at 2 ohms
- Efficient design produces high output with less drain on your boat battery
- Self-resetting 125 A electronic fuse means there is no fuse to replace
- Ignition Safety Protected and built to resist the marine environment
- Integrates seamlessly with Apollo and DSP-enabled Fusion marine stereos
No exploded diagram available for this product.
No compatible transducers listed for this product.
No compatible products found.
Amplifier
| Channels | 1 (monoblock) |
| Power (RMS) at 4 Ω | 650 W x 1 @ 14.4 V, <1% THD |
| Power (RMS) at 2 Ω | 1100 W x 1 @ 14.4 V, <1% THD |
| Total power | 2000 W |
| Class | Class-D |
| THD | <1% at rated power |
| Input sensitivity | 2.15 V RMS |
| Input impedance | 22 kΩ |
Electrical
| Supply voltage | 12 V DC (10.8 V - 16 V) |
| Fuse rating | 125 A self-resetting electronic fuse |
Installation
| Dimensions (W x D x H) | 235 x 180 x 45 mm |
| Marine rating | IPX2, Ignition Safety Protected |
General
| Weight | 2.2 kg |
| Warranty | 2 years |
