Victron AGM Super Cycle Battery 12V/15Ah (M5)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Energy AGM Super Cycle is a 12V 15Ah valve-regulated lead-acid (VRLA) battery built for cyclic use. Improved positive-plate paste and electrolyte additives make the cells far more tolerant of deep discharge, so the battery withstands repeated heavy cycling that would quickly damage a conventional AGM.
Victron recommends the Super Cycle range for applications where an occasional discharge to 100% depth of discharge, or frequent discharge to 60-80% DoD, is expected. The chemistry also gives a slightly smaller, lighter case and lower internal resistance than Victron's standard deep-cycle AGM batteries.
As a sealed, maintenance-free AGM, it can be mounted in most orientations and needs no topping up, making it a practical house or service battery for smaller marine and leisure installations.
PRODUCT DETAILS
- Sealed, maintenance-free AGM (VRLA) construction
- 12V nominal, 15Ah at the 20-hour rate (14Ah C10, 13Ah C5 to 10.8V)
- Improved plate paste and electrolyte additives for deep-discharge tolerance
- At least 300 cycles at 100% DoD; ~700 at 60% DoD; ~1000 at 40% DoD
- Suited to occasional 100% DoD or frequent 60-80% DoD use
- Smaller, lighter and lower internal resistance than standard Victron deep-cycle AGM
- M5 insert terminals
- Dimensions 151 x 100 x 103 mm; weight 4.1 kg
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Key specifications
| Technology | AGM (VRLA), Super Cycle |
| Nominal voltage | 12 V |
| Rated capacity (C20) | 15 Ah |
| Terminals | M5 insert |
| Weight | 4.1 kg |
Capacity
| Capacity at C5 | 13 Ah |
| Capacity at C10 | 14 Ah |
| Capacity at C20 | 15 Ah |
Charging
| Absorption voltage | 14.2 - 14.6 V |
| Float voltage | 13.5 - 13.8 V |
| Storage voltage | 13.2 - 13.5 V |
| Temperature compensation | -24 mV/°C |
Cycle life
| Cycle life at 100% DoD | 300 cycles |
| Cycle life at 60% DoD | 700 cycles |
| Cycle life at 40% DoD | 1000 cycles |
Physical
| Dimensions (l×w×h) | 151 x 100 x 103 mm |
