Blue Sea ML Series HD Auto Charge Relay 24V

ML SERIES AUTOMATIC CHARGING RELAY (Magnetic Latching)

500 Amp magnetic latching (bi-stable) relay automatically combines batteries during charging and isolates batteries when discharging and when starting engine

500 Ampere continuous rating

Bi-Stable Magnetic Latch (ML) draws very low current in the ON state

Start Isolation (SI) can be configured for temporary isolation of House loads from Engine circuit during engine cranking to protect sensitive electronics

Engine Isolation (EI) can be configured for isolation of two engines while both are running to protect engine electronics and maximize alternator output

Manual override knob provides an added level of safety allowing manual ON-OFF control with or without power while offering LOCKED OFF capability for servicing

Senses charging on two battery banks

3/ 8"-16 tin-plated copper studs for maximum conductivity and corrosion resistance

7/ 8" (22mm) stud length accepts multiple cable terminals

Label recesses for circuit identification

Silver alloy contacts provide high reliability for live switching
