Victron GX Touch 70 Flush Mount Victron GX Touch 70 Flush Mount
Victron GX Touch 70 Flush Mount

Victron

Victron GX Touch 70 Flush Mount

£417.60
Tax included.
BPP900455170
Seven inch flush-mount touchscreen for the Victron Cerbo GX, giving an at-a-glance system overview and direct settings control over a single cable. IP65 rated for exposed helm and marine installations, with a 1024 x 600 display and 2 metre cable.
✓ Available for collection or delivery in ~2 days

Pickup available at Mercury Yacht Harbour

Usually ready in 2-4 days

Description

The GX Touch 70 Flush is a seven inch touchscreen display for the Victron Cerbo GX, giving an instant on-board overview of the system and direct control of its settings. It connects to the Cerbo GX with a single cable, so there is no need to bring multiple wires to the screen, and it shows battery state of charge, consumption, PV and generator harvest, tank levels and temperatures at a glance.

This is the flush-mount version, designed to sit neatly behind a panel cut-out for a clean dashboard finish. It carries an IP65 rating, making it suitable for exposed helm and marine locations where the standard top or wall mount display would not be protected. The flush versions are supplied without the UV protection cover fitted to the top-mount models.

The larger seven inch screen suits dashboards where the display is read from a distance. It is powered from the Cerbo GX over the supplied 2 metre cable and operates across the full 8 to 70 VDC system range.

PRODUCT DETAILS

  • Seven inch capacitive touchscreen for the Victron Cerbo GX
  • Larger screen for reading at a distance from the helm
  • Flush-mount form for a clean panel cut-out finish
  • IP65 rated for exposed helm and marine locations
  • Single-cable connection to the Cerbo GX
  • 1024 x 600 resolution; powered from the Cerbo GX over the supplied 2 metre cable

No compatible transducers listed for this product.

Victron Cerbo GX MK2

Victron Cerbo GX MK2

No compatible products found.

Key specifications

Device typeFlush-mount touchscreen display for Cerbo GX
Display7 inch (17.8 cm) capacitive touchscreen
Supply voltage8 to 70 VDC (powered from the Cerbo GX via the display cable)
ConnectivitySingle cable to Cerbo GX
Protection category (IP)IP65

Display

Display resolution1024 x 600
Cable length2 m

Physical

Dimensions (h×w×d)120 × 184 × 13 mm

Operating conditions

Operating temperature range-20 to +50 °C

No videos available for this product.

What is the difference between the flush and standard GX Touch 70?
The flush version mounts behind a panel cut-out for a flush dashboard finish and is rated IP65, whereas the standard model is a top or wall mount. The flush version is also supplied without the UV protection cover.
Should I choose the GX Touch 50 or 70?
Both work identically with the Cerbo GX. The 70 has a larger seven inch, 1024 x 600 screen that is easier to read from a distance, while the 50 is a more compact five inch panel.
Does the GX Touch 70 Flush need its own power supply?
No. It is powered from the Cerbo GX over the supplied 2 metre cable, so no separate supply is required.
Is it suitable for an open or exposed helm?
Yes. The flush version is rated IP65, which makes it suitable for exposed helm and marine locations where the standard top or wall mount display would not be protected.
