Victron Orion XS 12/12-70A DC-DC Battery Charger
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Orion XS 12/12-70A is a high-efficiency DC-DC battery charger for dual battery systems in vehicles and boats with a 12V input and 12V output, delivering up to 70A. It charges a service battery from the starter battery or alternator and is engineered for systems with a Euro 5 or Euro 6 smart alternator, where the charging voltage is often too low to fully charge the service battery, and for long cable runs where voltage drop reduces charge voltage at the battery.
An integrated engine shutdown detection mechanism establishes whether the engine is running and only activates the charger when the alternator is supplying power, protecting the starter battery from deep discharge. The adaptive four-stage charge algorithm (bulk, absorption, float and storage) shortens the absorption time after shallow discharges and extends it after deep discharges, with fully programmable charge profiles and eight pre-programmed battery settings for lead-acid and lithium batteries.
Built-in Bluetooth Smart, a VE.Direct port and VE.Smart Networking allow the charger to be configured and monitored through the VictronConnect app and to receive voltage, temperature and current data from a compatible monitor such as a SmartShunt or BMV. This model has an IP20 protection rating and is intended for installation in a dry indoor environment, although the power electronics are enclosed in an IP65 housing. An unlimited number of units can be connected in parallel to increase output current.
PRODUCT DETAILS
- 12V input, 12V output DC-DC battery charger, up to 70A and 1000W
- Adaptive four-stage charge algorithm (bulk, absorption, float, storage)
- Fully programmable charging with eight pre-programmed battery profiles for lead-acid and lithium
- Engine shutdown detection for use with Euro 5 and Euro 6 smart alternators
- Built-in Bluetooth Smart, VE.Direct port (DVCC) and VE.Smart Networking
- Adjustable charge current in 0.1A steps via VictronConnect
- IP20 rated for dry indoor installation, power electronics in an IP65 housing
- Can be paralleled and switched remotely via remote on/off or VictronConnect
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Key specifications
| Input voltage range | 9-17 V |
| Output voltage (nominal) | 12 V (adjustable 10-17 V) |
| Continuous output current | Up to 70 A |
| Continuous output power | 1000 W |
| Galvanic isolation | Non-isolated |
| Bluetooth | Yes |
| Protection category | IP20 (power electronics in IP65 housing) |
Input
| Input voltage range | 9-17 V |
| Input current setting range | 1-70 A |
Output
| Output voltage adjust range | 10-17 V |
| Output voltage tolerance | +/- 0.25 % (max) |
| Output voltage noise | 10 mV rms |
| Output current setting range | 1-70 A |
| Maximum constant short-circuit current | 70 A |
| Continuous output power up to 40 C | 1000 W (at 14.3 V) |
| Maximum efficiency | 98.5 % |
Charger
| Charge algorithm | Adaptive four-stage (bulk, absorption, float, storage) |
| Battery presets | Eight pre-programmed settings, fully programmable |
| Battery types | Lead-acid and lithium |
| Charge current step size | 0.1 A |
| Engine shutdown detection | Yes |
| Can be used as power supply | Yes, output voltage set with VictronConnect |
General
| No-load current consumption | < 100 mA |
| Standby current consumption | < 1.5 mA |
| Bluetooth | Yes (VictronConnect / Bluetooth Smart) |
| VE.Smart Networking | Yes |
| VE.Direct | Yes (including DVCC) |
| Remote on/off | Yes |
| Parallel operation | Yes, unlimited number of units |
| Cooling | Natural convection (fanless) |
Environmental
| Operating temperature range | -20 to +60 C (derating 1.5 % per C above 40 C) |
| Humidity | 95 %, non-condensing |
| Maximum altitude | 2000 m |
| Protection category | IP20 (intended for dry indoor installation) |
Physical
| DC connection | Screw terminals |
| Maximum cable cross-section | 4 AWG (25 mm2) |
| Weight | 0.340 kg |
| Dimensions (h x w x d) | 137.3 x 123.1 x 40 mm |
Conformance
| Safety | IEC 62477-1 |
| EMC | EN 300 328, EN 301 489-1, EN 301 489-17, FCC 15B, ICES-003 |
| Automotive Directive | ECE R10-7 |
