Description
The Raymarine CCM-216 W is a YachtSense digital-switching Circuit Control Module providing 2 individually switched power output channels alongside 16-circuit current-sensing inputs. Each switched output can control an independent DC load - such as navigation lights, pumps, fans or deck equipment - while the current-sensing inputs continuously monitor the draw on up to 16 existing circuits. All channels are configurable via a compatible Raymarine display or YachtSense Link hub connected over the SeaTalkng (STng) backbone, enabling scheduling, safety cut-offs and real-time energy monitoring from the helm. Waterproof (IP66) enclosure for exposed or cockpit installation.
PRODUCT DETAILS
- 2 individually switched output channels for direct load control
- 16-circuit current-sensing inputs for real-time load monitoring
- Connects directly to SeaTalkng (STng) backbone - single bus power and data
- 12 V DC operating voltage
- Circuit names, scheduling and safety cut-offs configurable via YachtSense display
- Waterproof (IP66) enclosure for exposed or cockpit installation
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Electrical
| Input Voltage | 12 V DC |
| Switched Output Channels | 2 |
| Current-Sensing Channels | 16 |
Connectivity
| Network Interface | SeaTalkng (STng) backbone |
General
| Waterproofing | Waterproof (IP66) |
| Compatible System | Raymarine YachtSense digital-switching |
