Raymarine gS165 15.4in Glass Bridge Dual Display Bundle (6 o'clock optimal viewing)
Description
The Raymarine gS165 is a 15.4-inch Glass Bridge multifunction display, the flagship of Raymarine's LightHouse II range. Its edge-to-edge optically styled glass front, fast multi-touch interface and high-bandwidth gigabit networking make it the centrepiece of a fully integrated navigation, radar, sonar and entertainment system.
The gS165 brings together chartplotting, radar, sonar, thermal and video imaging, autopilot control and engine data on a single 16:9 1280 x 800 pixels display. It runs LightHouse II, with a responsive home screen, customisable pages and split-screen views, and supports C-MAP and Navionics cartography. Built-in Wi-Fi and Bluetooth allow remote viewing through the Raymarine app and wireless media control.
Designed as a true glass-bridge helm display, the gS165 has no built-in sonar; instead it connects to Raymarine's range of external DownVision, SideVision and CHIRP sonar modules over the high-speed SeaTalkhs network, so you can scale the fishfinding capability to your boat. It also networks seamlessly with Raymarine radar, Evolution autopilots, AIS, instruments and Fusion entertainment systems.
This dual-display bundle supplies two gS165 displays, ideal for building a twin-helm or flybridge installation where the Data Master and a networked repeater share charts, radar and sonar over SeaTalkhs.
This variant is optimised for a 6 o'clock viewing position (inverted mounting), giving the best contrast and colour when the display is viewed from below its centre line, such as when fitted into a console or helm below eye level.
PRODUCT DETAILS
- Dual-display bundle: two gS165 Glass Bridge displays for twin-helm or flybridge installations
- 15.4-inch TFT LED Glass Bridge multifunction display running Raymarine LightHouse II
- 1280 x 800 pixels (WVGA) resolution, 24-bit colour, 16:9 aspect ratio for sharp, vivid chart, radar and sonar imagery
- Fast multi-touch HybridTouch operation, with optional RMK-9 remote keypad control
- Gigabit (10 / 100 / 1000 Mbit/s) SeaTalkhs networking with Power over Ethernet for high-bandwidth radar, sonar and video
- No built-in sonar: connects to external Raymarine DownVision, SideVision and CHIRP sonar modules over SeaTalkhs
- Networks with Raymarine radar, Evolution autopilots, AIS, instruments and Fusion entertainment systems
- Built-in Wi-Fi and Bluetooth for the Raymarine mobile app and wireless media player control
- Internal GPS, with support for external RS130 / Raystar125 GNSS receivers
- HDMI video output and dual composite video inputs for thermal camera and video integration
- Optimised for a 6 o'clock (inverted) viewing position
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Display
| Screen size | 15.4 in. |
| Display type | TFT backlit LED |
| Colour depth | 24-bit |
| Resolution | 1280 x 800 pixels (WVGA) |
| Aspect ratio | 16:9 |
| Touchscreen | Multi-touch (HybridTouch operation with optional RMK-9 remote keypad) |
| Operating system | Raymarine LightHouse II |
GNSS receiver
| Internal GNSS | Internal GPS receiver |
| External GNSS options | RS130 GPS, Raystar125 GPS or Raystar125+ GPS (via optional SeaTalk to SeaTalkng converter), or NMEA 0183 GNSS receiver |
Networking
| NMEA 0183 | 2 x NMEA 0183 ports (Port 1: input and output, 4800 / 38400 baud; Port 2: input only, 4800 / 38400 baud) |
| Ethernet (SeaTalkhs) | 3 x RayNet (SeaTalkhs) ports, 10 / 100 / 1000 Mbit/s with PoE |
| SeaTalkng / NMEA 2000 | 1 x SeaTalkng connection (NMEA 2000 via optional DeviceNet adaptor) |
| SeaTalk | Supported via optional SeaTalk to SeaTalkng converter |
| Wi-Fi | 802.11 b / g |
| Bluetooth | Bluetooth 2.1 + EDR, power class 1.5 (AVRCP 1.0) |
| Remote card reader | 1 x Remote Card Reader connection |
| Alarm | 1 x Alarm output |
Video
| Video output | 1 x HDMI output |
| Video inputs | 2 x composite video inputs (PAL or NTSC) |
Sonar
| Built-in sonar | None (connect an external Raymarine sonar module over the SeaTalkhs network) |
| External sonar modules | Compatible with Raymarine DownVision, SideVision and CHIRP sonar modules connected via the SeaTalkhs network |
Mounting
| Mounting methods | Flush mount or surface mount (trunnion / bracket mounting not standard for glass bridge models) |
Physical
| Width | 383.2 mm (15 in.) |
| Height | 284.7 mm (11.2 in.) |
| Depth (excluding cables) | 77 mm (3 in.) |
| Depth (including cables) | 198 mm (7.8 in.) |
| Weight (bare unit) | 5.2 kg (11.5 lbs) |
Power
| Nominal supply voltage | 12 V dc to 24 V dc |
| Operating voltage range | 10.8 V dc to 31.2 V dc |
| Fuse / breaker | In-line fuse fitted within power cable: 15 A (standard 20 mm glass fuse) |
| Power consumption (without PoE) | Full brightness: 56.2 W Max; PowerSave mode: 15.1 W Max; Standby: 5 W Max |
| Power consumption (with PoE) | Full brightness: 85.7 W Max; PowerSave mode: 43 W Max; Standby: 40 W Max (full load of 20 W PoE) |
Environmental
| Operating temperature | -25 C to +55 C (-13 F to 131 F) |
| Storage temperature | -30 C to +70 C (-22 F to 158 F) |
| Relative humidity | Maximum 75% |
| Waterproof rating | IPX6 |
Conformance
| Conformance | NMEA 2000 certified; conformance certification applies to all display variants. Supports C-MAP Essentials, C-MAP 4D MAX, C-MAP 4D MAX+ and Navionics cartography. |
