Raymarine Type 1 12 Volt Autopilot Hydraulic Pump Motor
Description
The Raymarine Type 1 12V hydraulic pump motor is the reversing hydraulic pump assembly at the heart of a Raymarine Type 1 hydraulic autopilot drive. Driven by the autopilot's actuator control unit, it controls the flow of fluid through the boat's existing hydraulic steering system so the pilot can steer the boat.
This unit is matched to Type 1 hydraulic steering installations, sized for steering rams of 80 to 230cc, and runs on a 12-volt DC supply. It forms the drive element of an Evolution or SmartPilot autopilot system and works alongside the EV-1 sensor core, actuator control unit and control head.
PRODUCT DETAILS
- Reversing hydraulic pump motor for Raymarine Type 1 hydraulic autopilot drives
- Drives fluid through the boat's existing hydraulic steering system under autopilot control
- Matched to Type 1 installations with steering rams of 80-230cc
- For 12-volt DC electrical systems
- Forms the drive (muscle) of an Evolution or SmartPilot autopilot system
- Reversing pump operation for accurate, well-damped steering
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Drive
| Drive type | Reversing hydraulic pump motor |
| Drive classification | Type 1 |
| Hydraulic ram capacity | 80 to 230cc |
| Steering type | Hydraulic steering |
Power
| Supply voltage | 12 V dc |
Compatibility
| Autopilot system | Evolution / SmartPilot |
