Description
This adapter bridges a standard computer-style RJ45 Ethernet plug to the yellow 5-pin waterproof connector used on B&G and Simrad networks. It is wired as a crossover, which is what is required when connecting directly to a PC or to a device expecting a crossed link rather than going through a switch.
Typical uses are software updates, chart transfers, diagnostics and service work where a laptop needs to talk to a networked display or black-box module.
PRODUCT DETAILS
- RJ45 male to yellow 5-pin female Ethernet adapter
- Crossover wiring for direct device-to-device connection
- Links a laptop or standard Ethernet lead to a B&G / Simrad network
- Useful for service, diagnostics and software updates
No exploded diagram available for this product.
No compatible transducers listed for this product.
No spares or accessories listed for this product.
No compatible products found.
Connector
| Input | RJ45 male |
| Output | Yellow 5-pin female |
| Wiring | Crossover |
