Victron AGM Deep Cycle Battery 12V/110Ah
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron 12V/110Ah AGM Deep Cycle battery is a sealed valve-regulated lead-acid (VRLA) battery using absorbent glass mat technology, with the electrolyte absorbed into a glass-fibre mat between the plates. It is maintenance free and can be installed in most orientations without spillage.
The low internal resistance of AGM gives strong high-current performance for inverters, thrusters, winches, and engine starting, alongside deep-cycle house service. This 110Ah battery provides 500 A cold cranking and 170 minutes reserve capacity, making it a capable choice for larger auxiliary banks.
High-purity materials and lead-calcium grids keep self-discharge below 2% per month at 20°C, supporting long storage between charges when kept cool. Avoiding repeated deep discharge helps extend the working life of the battery.
PRODUCT DETAILS
- Sealed maintenance-free VRLA AGM construction
- 12V nominal, 110Ah rated capacity at the 20 hour rate (C20)
- Cold cranking 500 A; reserve capacity 170 minutes
- Very low internal resistance for inverters, thrusters and winches
- Self-discharge below 2% per month at 20°C
- Cycle design life of 400 cycles at 80% depth of discharge
- Float design life of 7 to 10 years at 20°C
- Copper terminals; 330 x 171 x 220 mm body, 32 kg
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Key specifications
| Technology | Flat plate AGM (VRLA) |
| Nominal voltage | 12 V |
| Rated capacity (C20) | 110 Ah |
| Terminals | Copper |
| Weight | 32 kg |
Capacity
| Rated capacity at 20h discharge | 110 Ah |
| Cold cranking amps (CCA) | 500 A |
| Reserve capacity | 170 min |
Charging
| Absorption voltage | 14.2 - 14.6 V |
| Float voltage | 13.5 - 13.8 V |
| Storage voltage | 13.2 - 13.5 V |
| Maximum charge current | 0.2 C |
| Temperature compensation | -24 mV/°C |
Cycle life
| Float design life at 20°C | 7 - 10 years |
| Cycle life at 80% DoD | 400 cycles |
| Cycle life at 50% DoD | 600 cycles |
| Cycle life at 30% DoD | 1500 cycles |
| Self-discharge at 20°C | < 2 %/month |
Physical
| Dimensions (l×w×h) | 330 x 171 x 220 mm |
