Victron
Victron AGM Deep Cycle Battery 12V/130Ah
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Energy 12V 130Ah AGM Deep Cycle is a sealed, maintenance-free VRLA battery using flat plate Absorbent Glass Mat construction. With the electrolyte held in a glass-fibre mat between the plates, the battery is spill-proof and can be installed in any orientation. Its low internal resistance makes it well suited to marine loads that draw high currents, including inverters, bow thrusters and electric winches.
The 130Ah rating is quoted at the 20 hour rate, with 120Ah available at the faster 10 hour rate. Lead-calcium grids and high-purity active materials keep self-discharge below 2% per month, allowing the battery to be left for long periods between charges. As with any lead-acid battery, service life is longest when discharges are kept shallow and the battery is recharged promptly with an appropriate charger.
It is supplied with flat copper terminals and offers 550A cold cranking and 200 minutes reserve capacity, making it a practical choice for house and service banks on cruising and liveaboard vessels.
PRODUCT DETAILS
- Sealed maintenance-free VRLA AGM construction, spill-proof and mountable in any position
- 130Ah rated capacity at the 20 hour rate (120Ah at the 10 hour rate)
- Low internal resistance for high-current loads such as inverters, thrusters and winches
- Flat copper terminals for a reliable connection
- Self-discharge below 2% per month at 20°C from lead-calcium grids
- Float design life of 7 to 10 years at 20°C
- Cycle design life of 400 cycles at 80% DoD, 600 at 50% DoD and 1500 at 30% DoD
- Cold cranking performance of 550A and 200 minutes reserve capacity
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Key specifications
| Technology | Flat plate AGM (VRLA) |
| Nominal voltage | 12 V |
| Rated capacity (C20) | 130 Ah |
| Terminals | Copper |
| Weight | 38 kg |
Capacity
| Capacity at C10 | 120 Ah |
| Capacity at C20 | 130 Ah |
| Cold cranking amps (CCA) | 550 A |
| Reserve capacity | 200 min |
Charging
| Absorption voltage | 14.2 - 14.6 V |
| Float voltage | 13.5 - 13.8 V |
| Storage voltage | 13.2 - 13.5 V |
| Maximum charge current | 26 A (0.2C) |
| Temperature compensation | -24 mV/°C |
Cycle life
| Float design life at 20°C | 7 - 10 years |
| Cycle life at 80% DoD | 400 cycles |
| Cycle life at 50% DoD | 600 cycles |
| Cycle life at 30% DoD | 1500 cycles |
| Self-discharge at 20°C | <2 %/month |
Physical
| Dimensions (l×w×h) | 410 x 176 x 227 mm |
