Victron AGM Deep Cycle Battery 12V/165Ah
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Energy 12V 165Ah AGM Deep Cycle is a sealed, maintenance-free VRLA battery built on flat plate Absorbent Glass Mat construction. The electrolyte is absorbed into a glass-fibre mat between the plates, making the battery spill-proof and suitable for mounting in any orientation. Low internal resistance gives strong high-current performance for marine loads such as inverters, bow thrusters and electric winches.
The 165Ah rating is quoted at the 20 hour rate, with 150Ah available at the faster 10 hour rate. Lead-calcium grids and high-purity materials hold self-discharge below 2% per month, so the battery tolerates long periods between charges. Service life is maximised by keeping discharges shallow and recharging promptly with a suitable three or four step charger.
With flat copper terminals, 600A cold cranking and 220 minutes reserve capacity, this battery is a dependable mid-to-large house bank option for cruising yachts and motor vessels.
PRODUCT DETAILS
- Sealed maintenance-free VRLA AGM construction, spill-proof and mountable in any position
- 165Ah rated capacity at the 20 hour rate (150Ah at the 10 hour rate)
- Low internal resistance for high-current loads such as inverters, thrusters and winches
- Flat copper terminals for a reliable connection
- Self-discharge below 2% per month at 20°C from lead-calcium grids
- Float design life of 7 to 10 years at 20°C
- Cycle design life of 400 cycles at 80% DoD, 600 at 50% DoD and 1500 at 30% DoD
- Cold cranking performance of 600A and 220 minutes reserve capacity
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Key specifications
| Technology | Flat plate AGM (VRLA) |
| Nominal voltage | 12 V |
| Rated capacity (C20) | 165 Ah |
| Terminals | Copper |
| Weight | 47 kg |
Capacity
| Capacity at C10 | 150 Ah |
| Capacity at C20 | 165 Ah |
| Cold cranking amps (CCA) | 600 A |
| Reserve capacity | 220 min |
Charging
| Absorption voltage | 14.2 - 14.6 V |
| Float voltage | 13.5 - 13.8 V |
| Storage voltage | 13.2 - 13.5 V |
| Maximum charge current | 33 A (0.2C) |
| Temperature compensation | -24 mV/°C |
Cycle life
| Float design life at 20°C | 7 - 10 years |
| Cycle life at 80% DoD | 400 cycles |
| Cycle life at 50% DoD | 600 cycles |
| Cycle life at 30% DoD | 1500 cycles |
| Self-discharge at 20°C | <2 %/month |
Physical
| Dimensions (l×w×h) | 485 x 172 x 240 mm |
