Victron AGM Deep Cycle Battery 12V/240Ah (M8)
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron Energy 12V 240Ah AGM Deep Cycle is the largest battery in the 12V AGM Deep Cycle range, a sealed maintenance-free VRLA unit built on flat plate Absorbent Glass Mat construction. The electrolyte is absorbed into a glass-fibre mat between the plates, making the battery spill-proof and suitable for mounting in any orientation. Low internal resistance gives strong high-current performance for demanding marine loads such as inverters, bow thrusters and electric winches.
Rated at 240Ah on the 20 hour discharge, it provides substantial reserve for liveaboard and large-vessel house banks. Lead-calcium grids and high-purity active materials keep self-discharge below 2% per month, so the battery tolerates long periods between charges. Service life is maximised by limiting discharge depth and recharging promptly with a suitable three or four step charger.
It is fitted with M8 drilled, flat copper insert terminals for a direct, high-contact connection, well suited to permanently installed banks where heavy cabling is used.
PRODUCT DETAILS
- Sealed maintenance-free VRLA AGM construction, spill-proof and mountable in any position
- 240Ah rated capacity at the 20 hour rate, the largest 12V AGM Deep Cycle model
- Low internal resistance for high-current loads such as inverters, thrusters and winches
- M8 drilled flat copper insert terminals for a direct, high-contact connection
- Self-discharge below 2% per month at 20°C from lead-calcium grids
- Float design life of 7 to 10 years at 20°C
- Cycle design life of 400 cycles at 80% DoD, 600 at 50% DoD and 1500 at 30% DoD
- Cold cranking performance of 650A and 250 minutes reserve capacity
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Key specifications
| Technology | Flat plate AGM (VRLA) |
| Nominal voltage | 12 V |
| Rated capacity (C20) | 240 Ah |
| Terminals | M8 drilled flat copper insert |
| Weight | 67 kg |
Capacity
| Capacity at C20 | 240 Ah |
| Cold cranking amps (CCA) | 650 A |
| Reserve capacity | 250 min |
Charging
| Absorption voltage | 14.2 - 14.6 V |
| Float voltage | 13.5 - 13.8 V |
| Storage voltage | 13.2 - 13.5 V |
| Maximum charge current | 48 A (0.2C) |
| Temperature compensation | -24 mV/°C |
Cycle life
| Float design life at 20°C | 7 - 10 years |
| Cycle life at 80% DoD | 400 cycles |
| Cycle life at 50% DoD | 600 cycles |
| Cycle life at 30% DoD | 1500 cycles |
| Self-discharge at 20°C | <2 %/month |
Physical
| Dimensions (l×w×h) | 522 x 240 x 224 mm |
