Victron
Victron AGM Deep Cycle Battery 12V/38Ah
Pickup available at Mercury Yacht Harbour
Usually ready in 2-4 days
Description
The Victron 12V/38Ah AGM Deep Cycle battery is a sealed valve-regulated lead-acid (VRLA) battery using absorbent glass mat technology, with the electrolyte held in a glass-fibre mat between the plates. It is maintenance free and can be mounted in most orientations without risk of spillage.
The low internal resistance typical of AGM makes the battery suitable for high-current applications such as engine starting, while still serving as a deep-cycle house battery. At 38Ah it suits modest auxiliary banks and equipment that draws occasional heavy current.
High-purity materials and lead-calcium grids keep self-discharge below 2% per month at 20°C, so the battery tolerates long storage between charges when kept cool. Repeated deep discharge shortens service life, so keeping discharges shallow where possible is recommended.
PRODUCT DETAILS
- Sealed maintenance-free VRLA AGM construction
- 12V nominal, 38Ah rated capacity at the 20 hour rate (C20)
- Low internal resistance suits high-current and engine-start use
- Self-discharge below 2% per month at 20°C
- Cycle design life of 400 cycles at 80% depth of discharge
- Float design life of 7 to 10 years at 20°C
- Copper terminals; 197 x 165 x 170 mm body, 12.5 kg
No compatible transducers listed for this product.
No spares or accessories listed for this product.
Key specifications
| Technology | Flat plate AGM (VRLA) |
| Nominal voltage | 12 V |
| Rated capacity (C20) | 38 Ah |
| Terminals | Copper |
| Weight | 12.5 kg |
Capacity
| Rated capacity at 20h discharge | 38 Ah |
Charging
| Absorption voltage | 14.2 - 14.6 V |
| Float voltage | 13.5 - 13.8 V |
| Storage voltage | 13.2 - 13.5 V |
| Maximum charge current | 0.2 C |
| Temperature compensation | -24 mV/°C |
Cycle life
| Float design life at 20°C | 7 - 10 years |
| Cycle life at 80% DoD | 400 cycles |
| Cycle life at 50% DoD | 600 cycles |
| Cycle life at 30% DoD | 1500 cycles |
| Self-discharge at 20°C | < 2 %/month |
Physical
| Dimensions (l×w×h) | 197 x 165 x 170 mm |
